Overview
Configured for reversing motor control in VersaPoint distributed I/O systems, the General Electric IC220STR003-BA (IC220STR003 Reversing Motor Starter) provides direct electrical execution for three-phase motor circuits. The unit supports motors up to 1.5 kW with a 400 VAC output and a maximum current rating of 3.6 A. General Electric has discontinued this model.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC220STR003 |
| Spare Model | IC220STR003-BA |
| Brand | General Electric |
| Product Series | VersaPoint |
| Product Type | Reversing Motor Starter |
| Motor Rating | 1.5 kW |
| Output Voltage | 400 VAC |
| Output Phase | 3-phase |
| Maximum Current | 3.6 A |
| Manufacturer Status | Discontinued by manufacturer |
| Origin | USA |
| Weight | 0.5 kg |
| Dimensions | 6.5 x 10.8 x 22.5 cm |
Industrial Control and I/O Integration
The IC220STR003 operates as a motor control component within the General Electric VersaPoint platform. Its reversing function controls the phase sequence applied to a compatible three-phase motor circuit, allowing the motor to operate in either direction through the associated control logic.
The VersaPoint architecture supports distributed industrial control arrangements and I/O density scaling. However, system communication behavior depends on the installed VersaPoint bus coupler and network configuration. Therefore, firmware compatibility and communication parameters must be verified against the complete station configuration before replacement or commissioning.
Frequently Asked Questions
Q: What type of motor circuit does the IC220STR003 control?
A: The IC220STR003 is designed for reversing three-phase motor control and supports a 400 VAC output with a maximum current rating of 3.6 A.
Q: What is the maximum motor power rating?
A: The specified motor rating is 1.5 kW.
Q: Can the IC220STR003 be replaced without checking the system configuration?
A: No. The IC220STR003 is part of a VersaPoint installation. The connected bus coupler, control wiring, motor circuit, and system configuration should be checked before replacement.
Field Installation Guidelines
Disconnect and isolate all incoming power sources before installing or removing the motor starter. Confirm that the three-phase supply and connected motor circuit match the specified 400 VAC and 3.6 A maximum ratings.
Install the unit according to the mechanical requirements of the VersaPoint station. Keep motor power wiring separated from low-level control and communication wiring where practical. Route conductors to minimize electromagnetic interference and secure all terminals according to the applicable installation documentation.
Verify motor rotation after commissioning. Check the reversing control sequence under controlled conditions and confirm that the motor circuit operates in the required direction before placing the equipment into normal service.
