Overview
Configured for terminating the final expansion receiver in a VersaMax PLC communication chain, the GE Fanuc Emerson IC200ACC201 (IC200ACC201 Expansion Terminator) provides direct physical termination at the end of the expansion network. The component completes the receiver chain boundary and supports defined communication signal conditions within compatible VersaMax PLC system assemblies.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC200ACC201 |
| Brand | GE Fanuc Emerson |
| Product Line | VersaMax |
| Product Type | Expansion Terminator |
| Function | Terminates the last expansion receiver in a communication chain |
| Compatibility | VersaMax PLC Systems |
| Origin | Not specified |
| Weight | 0.38 lb (0.17 kg) |
| Operating Temp | 0 to 60 deg C |
| Storage Temp | -40 to 85 deg C |
| Relative Humidity | 5% to 95%, non-condensing |
| Shock | 15 g, 11 ms |
| Vibration | 1 g at 57-150 Hz |
| Power Consumption | Not specified |
| Spare Part | Yes |
VersaMax Backplane and Expansion Communication
The IC200ACC201 operates as a termination component within the VersaMax expansion communication structure. It does not perform analog or discrete I/O processing. Instead, it terminates the final expansion receiver in the chain and defines the physical endpoint of the connected expansion assembly.
Correct placement at the end of the receiver chain supports controlled signal transmission across the PLC expansion architecture. During system configuration or maintenance, technicians should verify the expansion receiver sequence and install the terminator only at the designated chain endpoint.
Frequently Asked Questions
Q: Where should the IC200ACC201 be installed?
A: The IC200ACC201 should be installed at the last expansion receiver in the applicable VersaMax PLC communication chain.
Q: Does the IC200ACC201 provide discrete or analog I/O channels?
A: No. The component functions as an expansion terminator and does not provide process input or output channels.
Q: Is a power consumption value specified for this component?
A: No specific power consumption value is provided in the available technical data.
Field Installation Guidelines
Confirm that the VersaMax expansion communication chain is correctly assembled before installing the terminator. Position the IC200ACC201 at the designated final expansion receiver location.
Inspect mating connectors for contamination, bent contacts, or mechanical damage before installation. Avoid applying excessive force to the component or associated expansion hardware.
Route communication and power wiring according to the applicable VersaMax installation requirements. Keep signal wiring separated from high-current switching conductors where practical. Verify cabinet grounding and shielding practices before system commissioning.
After installation, inspect the complete expansion chain and confirm that the terminator is installed only at the final required receiver position.
