Overview
Specification
| Parameter | Description |
|---|---|
| Model Number | DSAI 130 3BSE018292R1 |
| Module Type | Analog Input Board |
| System Compatibility | ABB Advant OCS / 800xA Automation Systems |
| Function | Acquires and converts analog sensor signals for controllers |
| Channels | 16 analog input channels |
| Input Signal Range | 0–10 V, 4–20 mA (configurable) |
| Resolution | 16-bit high-resolution conversion |
| Accuracy | ±0.1% of full scale |
| Update Rate | Up to 50 ms per channel |
| Input Impedance | >1 MΩ for voltage, 250 Ω for current |
| Input Voltage | 24 V DC typical |
| Power Consumption | ≤ 5 W |
| Operating Temperature Range | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature Range | –20°C to 70°C (–4°F to 158°F) |
| Humidity | 5% to 95% non-condensing |
| Mounting | Rack-mounted in standard ABB control cabinets |
| Diagnostics | LED indicators for channel and module status |
| MTBF | >100,000 hours typical in industrial environments |
| Certifications | Complies with ABB industrial and safety standards |
FAQ
It is fully compatible with ABB Advant OCS and 800xA automation systems.
Q2: How many analog input channels does it support?
The board supports 16 independent analog input channels.
Q3: What types of input signals can it process?
It can process 0–10 V voltage signals and 4–20 mA current signals.
Q4: Can it operate in harsh industrial environments?
Yes, it tolerates electrical noise, vibration, and temperature fluctuations reliably.
Q5: Does it provide diagnostics for monitoring?
Yes, built-in LEDs display channel and module operational status.
Q6: Is the installation process complex?
No, it integrates easily with minimal setup in standard ABB control racks.
