Overview
Specification
| Category | Specification |
|---|---|
| Manufacturer | ABB |
| Model | 1MRK002133-ACr07 |
| Module Type | Control Board |
| Function | Signal processing, logic operations, and control management |
| System Compatibility | ABB control and protection relay platforms |
| Supply Voltage | 24–48 V DC typical |
| Power Consumption | <12 W |
| Input Channels | Multiple digital and analog inputs |
| Output Channels | Relay outputs and digital signaling |
| Signal Processing | High-speed logic operations for real-time control |
| Diagnostics | On-board LEDs for status and fault monitoring |
| Operating Temperature | –25°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Humidity Rating | 5–95% non-condensing |
| EMC Compliance | IEC/EN 60255-26, IEC/EN 60255-27 |
| Vibration Resistance | IEC 60068-2-6 |
| Shock Resistance | IEC 60068-2-27 |
| Mounting Method | Plug-in module for ABB relay and control systems |
| Dimensions | Standard ABB control board size |
| Weight | Approximately 0.4–0.6 kg |
| Reliability | MTBF >100,000 hours |
| Maintenance | Field-replaceable, modular servicing |
| Certifications | CE / IEC / EN compliant |
FAQ
It provides reliable control and signal processing for ABB automation and protection systems.
Q2: Can it integrate with existing ABB relay platforms?
Yes, it is fully compatible with ABB control and protection relay systems.
Q3: Is the module suitable for harsh industrial environments?
Yes, it operates reliably under vibration, shock, EMC interference, and temperature extremes.
Q4: Can it be replaced easily in the field?
Yes, its modular plug-in design allows fast replacement without major downtime.
Q5: Does it require frequent maintenance?
No, the board is designed for high reliability with minimal maintenance requirements.
