Overview
Specification
| Specification | Details |
|---|---|
| Model | PM564-RP-ETH |
| Module Type | Programmable Logic Controller |
| System Compatibility | ABB Advant OCS |
| CPU Type | 32-bit RISC processor |
| Memory | 512 KB RAM, 4 MB flash |
| Programming Languages | IEC 61131-3, Ladder, Function Block, Structured Text |
| Communication Interfaces | Ethernet (TCP/IP), Serial RS-232/RS-485 |
| I/O Support | Modular I/O expansion via backplane |
| Power Supply | 24 VDC |
| Power Consumption | 15 W typical |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 5% to 95% non-condensing |
| Diagnostics | LED indicators and software-based diagnostics |
| Mounting | Rack or DIN rail mounting |
| Compliance | CE, UL listed, conforms to industrial EMC standards |
| Typical Applications | Process automation, chemical plants, water treatment, energy generation |
FAQ
A1: It supports IEC 61131-3 languages including Ladder, Function Block, and Structured Text.
Q2: Can this PLC be integrated with Ethernet networks?
A2: Yes, it features an Ethernet interface for fast and secure communication.
Q3: Is the module suitable for modular I/O expansion?
A3: Yes, the controller supports modular I/O expansion for scalable systems.
Q4: What is the operating temperature range?
A4: The module operates between 0°C and 60°C (32°F to 140°F).
Q5: Which systems are compatible with PM564-RP-ETH?
A5: It is fully compatible with ABB Advant OCS control systems.
