Overview
Specification
| Specification | Details |
|---|---|
| Model | NFCP502-W05 |
| Module Type | CPU Module |
| System Compatibility | YOKOGAWA CENTUM VP |
| Processor Type | 32-bit RISC processor |
| Internal Memory | 8 MB RAM, 16 MB flash |
| Communication Interfaces | Ethernet TCP/IP, serial RS-232/RS-422 |
| I/O Support | Supports networked I/O modules |
| Power Supply | 24 VDC |
| Power Consumption | 12 W typical |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 5% to 95% non-condensing |
| Diagnostics | LED indicators and software-based fault monitoring |
| Mounting | Rack mount or modular system installation |
| Compliance | CE, UL, industrial EMC standards |
| Typical Applications | Process automation, chemical plants, power generation, water treatment |
FAQ
A1: It is fully compatible with YOKOGAWA CENTUM VP automation systems.
Q2: Does this module support fault-tolerant operation?
A2: Yes, it provides integrated fault tolerance to ensure continuous operation.
Q3: Which communication interfaces are available?
A3: It supports Ethernet TCP/IP and serial RS-232/RS-422 connections.
Q4: Can the module integrate with additional I/O modules?
A4: Yes, its scalable architecture allows seamless networked I/O expansion.
Q5: What is the operating temperature range for this CPU?
A5: The module operates reliably between 0°C and 55°C (32°F to 131°F).
