Overview
Specification
| Specification | Details |
|---|---|
| Model | IC695ALG616 |
| Module Type | Analog Input Module |
| System Compatibility | GE Fanuc Rx3i and Rx7i PACSystems |
| Input Channels | 16 analog input channels |
| Input Signal Types | 0–10 V, ±10 V, 4–20 mA, ±20 mA |
| Resolution | 16-bit |
| Conversion Time | 1 ms per channel |
| Accuracy | ±0.1% of full scale |
| Isolation | 250 Vrms channel-to-channel and channel-to-system |
| Power Supply | 5 VDC via backplane |
| Power Consumption | 2.5 W typical |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -20°C to 85°C (-4°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Diagnostics | LED indicators for module status and channel errors |
| Hot-Swap Capability | Yes, supports module replacement without shutting down system |
| Mounting | DIN rail or PACSystems rack |
| Compliance | UL listed, CE marked, conforms to industrial EMC standards |
| Typical Applications | Process automation, chemical plants, power generation, factory automation |
FAQ
A1: It supports 16 analog input channels for versatile signal acquisition.
Q2: What input signal types are compatible with this module?
A2: The module supports 0–10 V, ±10 V, 4–20 mA, and ±20 mA signals.
Q3: Can this module be replaced without shutting down the system?
A3: Yes, it is hot-swappable for maintenance without interrupting operations.
Q4: What is the conversion resolution of the analog signals?
A4: It provides high-resolution 16-bit conversion for precise measurements.
Q5: Which PACSystems platforms are compatible with IC695ALG616?
A5: It integrates seamlessly with Rx3i and Rx7i PACSystems.
