The GE IS200AEPAH1BFC, also cataloged as the IS200AEPAH1BFC AEPA Printed Circuit Board, operates as a dedicated hardware component for pitch axis signal processing and interface control within GE Mark VI / Mark VIe turbine control platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS200AEPAH1BFC |
| Brand | General Electric (GE / GE Fanuc) |
| Origin | United States |
| Product Series | Mark VI / Mark VIe Control System |
| Product Type | Printed Circuit Board / AEPA Control Module |
| Functional Acronym | AEPA |
| Weight | Approx. 0.8 kg |
| Dimensions | Approx. 152 x 44 x 290 mm |
| Operating Temp | Storage range: -40 deg C to +70 deg C |
| Power Consumption | 125 VDC input supply rating |
| Humidity Range | 5% to 95% non-condensing |
| Configuration Support | Simplex and redundant Mark VIe architectures |
| Diagnostic Interface | Onboard LED status indicators |
GE Mark VIe Industrial Control Interface Characteristics
The IS200AEPAH1BFC integrates into GE Mark VI / Mark VIe architectures through rack-level electrical connections and multi-pin interfaces. It processes pitch axis related control signals and provides communication paths between field-level components and controller layers.
Furthermore, the board supports industrial control cabinet integration through modular connectors, diagnostic indicators, and protection components. The integrated metal oxide varistors (MOVs) provide transient voltage suppression for connected electrical circuits.
The module follows GE industrial control hardware practices, including firmware compatibility requirements, backplane communication interfaces, and I/O density scaling within the Mark VIe platform.
Frequently Asked Questions
Q: Does the IS200AEPAH1BFC support redundant control configurations?
A: Yes. The board is designed for Mark VI / Mark VIe system architectures that support simplex and redundant hardware arrangements.
Q: What installation precautions apply to the AEPA circuit board?
A: Installation requires correct rack alignment, connector engagement verification, proper grounding, and compliance with cabinet wiring practices.
Q: Does the board include onboard diagnostic functions?
A: Yes. The module includes LED indicators that provide local hardware status information for troubleshooting and maintenance activities.
Field Installation Guidelines
- Verify the rack slot assignment before inserting the IS200AEPAH1BFC module.
- Inspect connectors for contamination, mechanical damage, or incorrect pin alignment before installation.
- Maintain proper cabinet grounding and shielding practices for connected control wiring.
- Separate signal wiring from high-current power conductors to reduce electrical interference.
- Confirm compatible firmware and controller configuration before system commissioning.
