Overview
The GE IS210AEBIH1BEA, also cataloged as the IS210AEBIH1B AE Bridge Interface Card, operates as a dedicated hardware component for electrical interface and bridge communication functions within GE Mark VIe Wind control platforms. The conformal-coated printed circuit board receives +24 VDC supply power and operates across the specified industrial temperature and humidity ranges.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS210AEBIH1BEA |
| Spare Model | IS210AEBIH1B |
| Product Type | AE Bridge Interface Card |
| Product Parameters | Printed Circuit Board |
| Brand | General Electric (GE) |
| Series | Mark VIe Wind |
| Coating | Conformal Coating |
| Origin | USA |
| Weight | 0.3 kg |
| Dimensions | 29.2 x 13 x 2.5 cm |
| Operating Temp | 0 deg C to +60 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Consumption | Not specified |
| Power Supply | +24 VDC |
| Core Function | Electrical interface and bridge communication functions |
Industrial Control Communication and Firmware Compatibility
The IS210AEBIH1BEA is installed as a hardware-level interface card within the Mark VIe Wind control architecture. Its printed circuit board construction supports direct electrical integration with the associated system hardware. In addition, the conformal coating provides an additional protective layer on the board surface for specified industrial operating environments.
System compatibility depends on the installed Mark VIe Wind hardware configuration and the corresponding approved firmware environment. Therefore, the complete board model, IS210AEBIH1BEA, and the base model, IS210AEBIH1B, should be verified before replacement or system integration. Do not assume compatibility based only on similar board appearance or connector arrangement.
Frequently Asked Questions
Q: What is the supply voltage for the IS210AEBIH1BEA?
A: The specified power supply is +24 VDC. The field power source and associated wiring should be verified before energizing the card.
Q: Does the IS210AEBIH1BEA support hot swapping?
A: Hot-swap capability is not specified in the provided technical data. The card should not be removed or installed while energized unless the applicable GE system documentation explicitly permits that procedure.
Q: What environmental conditions are specified for operation?
A: The board operates from 0 deg C to +60 deg C with relative humidity from 5% to 95%, non-condensing.
Field Installation Guidelines
- Verify that the installed board matches the complete model IS210AEBIH1BEA before installation.
- Confirm the system requirement for the base model IS210AEBIH1B and the applicable Mark VIe Wind hardware configuration.
- Isolate system power before installation unless the approved system procedure specifically supports energized replacement.
- Inspect the printed circuit board, connectors, mounting points, and conformal-coated surfaces for physical damage before installation.
- Use appropriate electrostatic discharge precautions when handling the circuit board.
- Connect the +24 VDC supply according to the applicable system wiring documentation and verify polarity before energizing.
- Keep signal and communication wiring separated from high-power conductors where required by the control cabinet wiring design.
- Maintain proper grounding and shielding practices for associated control wiring to reduce electrical interference.
- After installation, verify board recognition and interface operation through the applicable Mark VIe Wind diagnostic procedure.
