Overview
Configured for internal communication and data transfer within the Mark VIe control architecture, the GE IS210AEBIH1BDA (IS210AEBI AE Bridge Interface Card) provides direct physical and electrical interface functions between system components. The card supports bridge-level data routing within compatible control assemblies and uses a conformally coated printed circuit board for additional environmental protection.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS210AEBIH1BDA |
| Base Model | IS210AEBI |
| Brand | GE Energy / General Electric |
| Product Type | AE Bridge Interface Card |
| Functional Acronym | AEBI |
| Series | Mark VIe / Mark VIe Wind |
| Application | Internal communication and bridge interface functions within compatible control assemblies |
| PCB Protection | Conformal coating |
| Mounting | Panel or rack mounting through standard mounting holes |
| Origin | United States |
| Weight | Approx. 0.75 lb / 0.34 kg |
| Core Performance | Internal data transfer and communication interface functions |
| Hardware Revision | H1BDA |
Backplane Communication and Firmware Compatibility
The GE IS210AEBIH1BDA operates as a hardware interface component within the Mark VIe control platform. Therefore, correct communication depends on the installed system architecture, compatible backplane connections, and matched hardware revisions.
The interface card transfers internal data between connected system components according to the applicable Mark VIe hardware configuration. Firmware and hardware compatibility should be verified before replacement or system modification. In addition, the installed revision should match the requirements of the associated control assembly.
Frequently Asked Questions
Q: Can the IS210AEBIH1BDA be installed in a system without checking the hardware revision?
A: No. The installed hardware revision and associated control assembly should be verified before installation. Compatibility depends on the specific Mark VIe system configuration.
Q: Does the IS210AEBIH1BDA provide direct field I/O connections?
A: The available data identifies this unit as an AE Bridge Interface Card for internal communication and bridge functions. Specific external field I/O capability is not stated in the provided technical information.
Q: Is a specific power consumption value available for this card?
A: No specific power consumption value is provided in the available technical data. The applicable system documentation should be checked for rack and power loading requirements.
Field Installation Guidelines
- Disconnect or isolate system power according to the applicable equipment maintenance procedure before installing or removing the card.
- Verify that the full model IS210AEBIH1BDA matches the required replacement position and hardware configuration.
- Inspect the conformal-coated PCB and connectors for physical damage before installation.
- Align the card with the designated mounting position and secure it using the specified mounting hardware.
- Avoid excessive mechanical force when engaging board connectors or backplane interfaces.
- Maintain separation between communication wiring and high-energy power conductors where applicable.
- Follow the grounding and shielding practices specified for the complete Mark VIe control assembly.
- After installation, verify communication status and system diagnostics before returning the equipment to service.
