Overview
Specification
| Parameter | Specification |
|---|---|
| Model | CI615 EXC3BHT300024R1 |
| Product Type | Advant OCS Bus Coupler for I/O Extension Units |
| System Compatibility | ABB Advant Controller Series (OCS / Master / Advant AC) |
| Primary Function | Communication interface between main controller and remote I/O |
| Power Supply | 24 V DC nominal |
| Bus Communication | Advant Fieldbus / I/O Extension Bus |
| Supported I/O Stations | Multiple remote I/O units depending on system configuration |
| Data Exchange Type | Cyclic and event-driven data transfer |
| Communication Stability | Low latency and high noise immunity |
| Status Indicators | Front-panel LEDs for bus activity, module health, and power |
| Installation Method | DIN-rail or rack-mounted (depending on system frame) |
| Cooling | Natural convection (no forced cooling required) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | –25°C to +70°C |
| Humidity Rating | 5% to 95% non-condensing |
| EMC Compliance | Industrial-grade EMI/EMC resistance |
| Dimensions | Standard ABB Advant I/O module form factor |
| Construction | Robust industrial PCB with reinforced connectors |
| Application Role | Expands remote I/O capacity in distributed process automation systems |
FAQ
It serves as a communication link between the Advant controller and remote I/O units, enabling stable system expansion.
Yes. It integrates smoothly with existing Advant OCS installations without major redesign work.
