Overview
In addition, this power supply module integrates seamlessly with central system units, supporting modular expansion and simplifying maintenance operations. Therefore, engineers can maintain stable system performance while minimizing downtime, which enhances overall process reliability and operational efficiency. Furthermore, the module complies with ABB standards for industrial power quality and safety.
Specification
| Parameter | Specification |
|---|---|
| Model / Part Number | 200-PSMG 492898801 |
| Module Type | Power Supply Module |
| Compatible Systems | ABB Advant OCS Central System Units |
| Input Voltage | 120/230 V AC ±10%, 50/60 Hz |
| Output Voltage | +5 V DC / +24 V DC (regulated) |
| Output Current | 5 A (5 V DC), 2.5 A (24 V DC) |
| Efficiency | ≥85% typical under rated load |
| Ripple & Noise | <50 mV peak-to-peak |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Cooling Method | Convection / Rack-mounted airflow |
| Dimensions | Standard 19-inch rack mount, 3U height |
| Weight | ~4.5 kg |
| Protections | Overvoltage, overload, short-circuit, thermal shutdown |
| Reliability | MTBF >100,000 hours (industrial conditions) |
| Mounting | Rack-mounted with screw locks |
| Standards Compliance | IEC/EN 60950, industrial EMC standards |
FAQ
A1: It supports 120/230 V AC at 50/60 Hz, allowing flexible installation across standard industrial environments.
Q2: Can this power supply module operate continuously under full load?
A2: Yes, it is designed for continuous operation with stable DC output at full rated current.
Q3: Does the module include protection against electrical faults?
A3: Yes, it has overvoltage, overload, short-circuit, and thermal shutdown protections.
Q4: How is the module mounted in a control rack?
A4: It mounts on a standard 19-inch rack using screw locks, ensuring secure installation.
Q5: Is the 200-PSMG compatible with redundant system configurations?
A5: Yes, it supports redundant and modular control setups for increased system reliability.
Q6: What is the typical operational temperature range?
A6: The module operates reliably between 0°C and +60°C, suitable for most industrial environments.
