Overview
Specification
| Category | Specification |
|---|---|
| Manufacturer | ABB |
| Model | 1MRK001608-CBr02 |
| Module Type | Communication Module |
| Function | Real-time data exchange and protocol management |
| System Compatibility | ABB control boards and protection relay platforms |
| Supported Protocols | IEC 61850, Modbus RTU/TCP, DNP3, Profibus (platform-dependent) |
| Data Rate | Up to 100 Mbps, protocol-dependent |
| Network Interfaces | RJ45, backplane connection, optional fiber interface |
| LED Indicators | Network status, activity, error, and power |
| Operating Temperature | –25°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Humidity Rating | 5–95% non-condensing |
| EMC Compliance | IEC/EN 60255-26, IEC/EN 60255-27 |
| Vibration Resistance | IEC 60068-2-6 |
| Shock Resistance | IEC 60068-2-27 |
| Mounting Method | Plug-in module for ABB relay and control systems |
| Dimensions | ABB standard module size |
| Weight | Approximately 0.3–0.5 kg |
| Reliability | MTBF >100,000 hours |
| Maintenance | Field-replaceable, modular servicing |
| Certifications | CE / IEC / EN compliant |
FAQ
It enables high-speed, real-time communication and protocol management in ABB automation systems.
Q2: Which protocols does this module support?
It supports IEC 61850, Modbus RTU/TCP, DNP3, and Profibus depending on platform configuration.
Q3: Is the module suitable for harsh industrial environments?
Yes, it operates reliably under vibration, shock, EMC interference, and wide temperature ranges.
Q4: Can the module be replaced easily in the field?
Yes, its plug-in design allows fast, straightforward replacement without system downtime.
Q5: Does it require frequent maintenance?
No, it is designed for high reliability and long operational intervals with minimal service.
