Overview
Specification
| Parameter | Specification |
|---|---|
| Number of outputs | 8 |
| Output voltage | 24 V DC |
| Output current | ≤ 2 A per channel |
| Output type | Binary, short-circuit-proof |
| Safety rating | DIN V 19250, requirement classes 1–4 |
| Supply voltage (outputs) | UP/ZP 24 V DC |
| Supply voltage (module electronics) | L+/M 24 V DC, electrically isolated |
| Communication interface | CS31 system bus |
| Indication | Yellow LEDs (signal/error), red LED (fault), test button |
| Address configuration | DIL switch (0–31) |
| Mounting | DIN rail or control cabinet rear wall |
FAQ
A: Yes, it integrates seamlessly with legacy Advant OCS racks, supporting smooth system upgrades.
Q: What safety standards does it meet?
A: The module maintains a safe off-state during faults, adhering to industrial safety requirements.
Q: How many modules can be installed in one rack?
A: Up to the system’s maximum supported channels, depending on the Advant OCS configuration.
