Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | VPM810 |
| Product Type | Valve Positioning Module / I/O Module |
| Suitable System | ABB 800 Series / Advant OCS / 800xA Turbine & Process Control Systems |
| Control Modes | Closed‑loop position control, Open‑loop I/H converter mode, Dual‑loop inner‑outer mode, Manual mode |
| Inputs | 2 position feedback inputs (AC LVDT, DC LVDT, AC LVRT or 4–20 mA), 2 digital inputs for limit switch or manual control |
| Outputs | Dual‑coil servo output (linear or integrating), relay outputs for solenoids or alarms, analog/digital I/O depending on configuration |
| Maximum Servo Output Current | 227 mA max for coil servo output |
| Power Supply | 24 V DC |
| Communication Interface | Profibus DP, supporting master-line redundancy and integration |
| Dimensions (approx.) | Depth 119 mm × Height 106 mm × Width 44 mm |
| Weight (net) | ~0.204 kg |
| Mounting / Installation | DIN‑rail or cabinet mounting; compatible with standard ABB 800‑series racks or terminal base units |
| Operating Environment | Industrial turbine or process control environments; suitable for retrofit and new installations under typical ambient conditions |
FAQ
A: VPM810 supports closed‑loop position control with feedback, open‑loop I/H converter mode, dual‑loop inner‑outer mode, and a manual override mode.
Q: Which feedback devices are compatible for position sensing?
A: The module accepts AC or DC LVDT, AC LVRT, or 4–20 mA position feedback devices.
Q: What communication interface does VPM810 use for system integration?
A: It uses Profibus DP for communication, with support for master-line redundancy.
Q: Can VPM810 be installed in existing turbine or control cabinets?
A: Yes — its compact size and standard 24 V DC supply make it suitable for retrofit or new installations within ABB 800‑series racks or DIN‑rail mounting.
Q: Is manual valve operation possible if controller communication fails?
A: Yes — the module provides a manual mode that allows operators to raise or lower valves via hard-wired commands when needed.
