Overview
Configured for servo signal execution in a GE industrial control platform, the GE IS210WSVOH1A (IS210WSVOH1A Servo Driver Board) provides direct electrical control of servo-related analog signals. It accepts a 24 VDC supply and +/-10 V analog inputs, with 16-bit resolution and a typical 1 kHz control bandwidth. The stated update rate is 62.5 us, corresponding to 16 kHz.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS210WSVOH1A |
| Brand | General Electric |
| Product Type | Servo Driver Board |
| Product Parameters | Servo Driver Board |
| Origin | USA |
| Weight | 0.52 kg |
| Dimensions | 26 x 15.2 x 3 cm estimated shipping size |
| Operating Temp | -20 deg C to +60 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Humidity | 5-95% non-condensing |
| Input Voltage | 24 VDC +/-10% |
| Power Consumption | 15 W typical |
| Isolation Voltage | 1500 V AC |
| Analog Inputs | +/-10 V |
| Control Bandwidth | 1 kHz typical |
| Resolution | 16-bit |
| Update Rate | 62.5 us, 16 kHz |
Industrial Control and Servo Signal Characteristics
The IS210WSVOH1A processes analog servo command signals through a +/-10 V input range. Its 16-bit resolution provides discrete digital representation of the applied analog command. Meanwhile, the specified 62.5 us update interval corresponds to a 16 kHz update rate, while the typical control bandwidth remains 1 kHz.
The board requires a 24 VDC supply within the stated +/-10% tolerance. Furthermore, the specified 1500 V AC isolation rating defines the stated electrical isolation capability between applicable circuits. Installation should therefore preserve the board’s intended isolation paths and prevent unintended conductive connections.
For GE industrial control architectures, installation should also maintain correct backplane or control-system interface compatibility. Firmware and hardware revision compatibility must be verified against the specific host system before replacement.
Frequently Asked Questions
Q: What supply voltage does the IS210WSVOH1A require?
A: The board uses a 24 VDC input supply with a specified tolerance of +/-10%.
Q: What analog input range does the board support?
A: The specified analog input range is +/-10 V.
Q: What are the stated resolution and update rate?
A: The board specifies 16-bit resolution and a 62.5 us update rate, equivalent to 16 kHz.
Field Installation Guidelines
- Verify the complete IS210WSVOH1A model designation and hardware revision before installation.
- Confirm that the host control system accepts the installed board revision and associated interface configuration.
- Isolate system power before removing or installing the board.
- Connect the 24 VDC supply with correct polarity and remain within the specified +/-10% supply tolerance.
- Route analog signal wiring separately from high-current switching and high-noise conductors where practical.
- Maintain appropriate cable shielding and terminate shields according to the control-system grounding design.
- Inspect connectors and board interfaces for contamination, mechanical damage, or loose contacts before energization.
- After installation, verify the analog input signal path before applying the servo command to the controlled circuit.
- Confirm that operating temperature and humidity remain within the stated environmental limits.
- Do not alter isolation paths or introduce external conductive connections that can compromise the specified electrical isolation.
