Overview
Configured for signal termination in Yokogawa ESB Bus systems, the Yokogawa S9341FA (S9341FA Terminator Module) provides direct physical and electrical termination at the end of the ESB communication network. The module reduces signal reflections at the bus endpoint and supports stable data transmission within compatible Yokogawa control system architectures, including CENTUM VP configurations where the ESB network is applied.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | S9341FA |
| Brand | Yokogawa |
| Product Type | ESB Bus Terminator Module / Connector Unit with Terminator |
| Compatibility | Yokogawa ESB Bus Systems / CENTUM VP DCS |
| Core Function | Terminates bus signals at the network endpoint |
| Signal Function | Reduces signal reflections and maintains bus signal integrity |
| Installation Position | End of the ESB communication network |
| Operating Temp | -10 deg C to +55 deg C |
| Storage Temp | -20 deg C to +70 deg C |
| Construction | Compact industrial connector and termination assembly |
DCS Communication and Process Control Integration
The S9341FA operates as a physical bus termination component rather than an active process I/O interface. Therefore, it does not perform 4-20 mA HART signal processing, channel-to-channel isolation, or cold junction compensation.
Within the Yokogawa DCS communication architecture, correct bus termination helps control electrical signal behavior at the endpoint of the ESB network. As a result, the installation arrangement can reduce reflected communication signals that may affect data transmission. The module should be installed according to the applicable Yokogawa ESB network configuration requirements.
Frequently Asked Questions
Q: What is the primary function of the Yokogawa S9341FA?
A: The S9341FA terminates the ESB bus at the designated network endpoint to reduce signal reflections on the communication line.
Q: Can the S9341FA be installed at any position on the ESB network?
A: No. The module is intended for installation at the designated end position of the ESB communication network. The network topology should follow the applicable Yokogawa system documentation.
Q: Does the S9341FA process analog or digital field signals?
A: No field signal processing function is specified. The module functions as a connector unit with bus termination for the ESB communication network.
Field Installation Guidelines
- Install the S9341FA only at the specified endpoint of the compatible ESB bus network.
- Confirm the ESB network topology before connecting the terminator module.
- Disconnect or isolate system power when required by the applicable site maintenance procedure.
- Ensure that connectors are fully seated and mechanically secured.
- Route communication cables separately from high-power conductors where practical.
- Follow the applicable Yokogawa grounding and shielding requirements for the ESB communication system.
- Do not install additional terminators unless the system network configuration specifically requires them.
- Verify the operating environment remains within the specified temperature range of -10 deg C to +55 deg C.
