Overview
The IS200VTCCH1CBB thermocouple terminal board manages temperature sensor wiring within the GE Mark VI turbine control system.
GE designed IS200VTCCH1CBB to connect multiple thermocouple sensors directly to turbine monitoring and protection hardware.
Additionally, the board routes low-level thermocouple signals toward control modules that process temperature measurements.
Therefore, IS200VTCCH1CBB supports stable temperature signal transmission across demanding turbine and power generation environments.
Moreover, dedicated signal paths reduce electrical noise and maintain measurement accuracy during continuous industrial operation.
Consequently, the Mark VI control processor receives precise temperature data for protection logic and performance monitoring.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IS200VTCCH1CBB |
| Manufacturer | General Electric (GE) |
| Product Type | Thermocouple Terminal Board |
| Series | GE Mark VI Turbine Control System |
| Board Function | Thermocouple signal wiring and interface distribution |
| Supported Sensors | Industrial thermocouple sensors (Type J, K, T, and similar types) |
| Thermocouple Channels | Up to 24 thermocouple input channels |
| Signal Type | Low-level millivolt thermocouple signals |
| Temperature Measurement Range | −200°C to +1250°C depending on thermocouple type |
| Connector Interface | High-density cable connectors for Mark VI control modules |
| Field Wiring Interface | Screw-type terminal blocks for thermocouple sensor connections |
| Signal Routing | Dedicated channel traces for low-noise signal transmission |
| Protection Components | Electrical noise suppression and surge protection circuits |
| Electronic Components | Industrial resistors, capacitors, terminal connectors, and signal routing components |
| PCB Construction | Multi-layer industrial PCB with reinforced copper signal paths |
| Energy Storage Components | Stabilizing capacitors for signal filtering |
| Power Requirement | Low-power signal interface board |
| Cooling Method | Passive airflow cooling within turbine control cabinet |
| Mounting Method | Cabinet-mounted terminal board assembly |
| Dimensions | Approximately 210 mm × 120 mm × 35 mm |
| Weight | Approximately 1.0 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | −40°C to 85°C |
| Relative Humidity | 5–95% non-condensing |
| System Compatibility | GE Mark VI turbine and generator control systems |
FAQ
Q1: Is the GE IS200VTCCH1CBB module brand new and original?
Yes. We provide IS200VTCCH1CBB as brand-new original factory equipment with guaranteed industrial quality.
Q2: Do you keep IS200VTCCH1CBB in stock?
Yes. Our warehouse usually keeps IS200VTCCH1CBB terminal boards in stock for immediate supply.
Q3: How quickly can you ship after receiving the order?
We normally ship IS200VTCCH1CBB within 3 days to 2 weeks depending on order quantity.
Q4: Which logistics companies handle international delivery?
We commonly arrange shipments through trusted global logistics providers such as DHL.
Q5: What sensor types work with IS200VTCCH1CBB?
The IS200VTCCH1CBB terminal board supports common thermocouple sensors including Type J, Type K, and Type T.
