Overview
The IS200TBAIH1CDC analog input terminal board supports precise signal acquisition inside GE Mark VI turbine control environments. Engineers select IS200TBAIH1CDC when they require reliable termination for multiple analog field devices.
Moreover, IS200TBAIH1CDC integrates easily with GE Mark VI I/O architecture and improves wiring organization across industrial control cabinets. The board connects field transmitters, sensors, and monitoring equipment directly to the controller interface.
Furthermore, IS200TBAIH1CDC provides stable analog signal routing while maintaining electrical isolation between field wiring and system electronics. Industrial plants therefore maintain high measurement accuracy across turbine, compressor, and generator control systems.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Product Model | IS200TBAIH1CDC |
| Product Type | Analog Input Terminal Board |
| Series | GE Mark VI Turbine Control System |
| Primary Function | Analog signal termination and distribution for turbine control I/O modules |
| Compatible I/O Module | Typically used with GE Mark VI analog input boards such as IS200VAICH1 series |
| Input Signal Types | 4–20 mA current signals and ±10 V voltage signals from field transmitters |
| Maximum Analog Channels | Up to 10–12 analog input field connections depending on system configuration |
| Terminal Type | Industrial screw-type terminal blocks for secure field wiring |
| Connector Interface | High-density board connectors linking terminal board to Mark VI I/O module |
| Isolation Design | Electrical isolation between field signals and controller electronics |
| Signal Conditioning | Includes passive components for filtering and stable analog signal transmission |
| Field Wiring Capacity | Supports multi-channel sensor wiring including transmitters, sensors, and monitoring devices |
| PCB Construction | Industrial-grade multilayer printed circuit board designed for control cabinet environments |
| Mounting Method | Panel mounting inside Mark VI control cabinet using mechanical standoffs |
| Board Dimensions | Approximately 280 mm × 180 mm × 30 mm |
| Net Weight | Approximately 0.7–0.9 kg |
| Connector Quantity | Multiple terminal connectors for field signals and internal system connections |
| Operating Temperature | Typically 0°C to 60°C for standard industrial cabinet operation |
| Storage Temperature | –40°C to 85°C during storage and transportation |
| Humidity Range | 5% to 95% non-condensing |
| Protection Features | Stable terminal locking structure to prevent signal interruption from vibration |
| Application Environment | Gas turbines, steam turbines, generator monitoring systems, and industrial automation cabinets |
FAQ
Q1: Is the IS200TBAIH1CDC terminal board new or refurbished?
All IS200TBAIH1CDC units we supply are brand new original factory sealed products.
Q2: Which GE control system supports IS200TBAIH1CDC?
The IS200TBAIH1CDC terminal board supports GE Mark VI turbine control systems and related analog I/O modules.
Q3: What analog signal types can IS200TBAIH1CDC process?
The IS200TBAIH1CDC board commonly handles industrial analog signals such as 4–20 mA current loops and ±10 V voltage inputs.
Q4: How quickly can you ship the IS200TBAIH1CDC board?
We usually ship IS200TBAIH1CDC within 3 days to 2 weeks, depending on order quantity and warehouse scheduling.
Q5: Which logistics companies handle delivery?
We frequently ship IS200TBAIH1CDC using DHL and other international express carriers for reliable global delivery.
