Overview
Moreover, the board’s compact yet robust construction simplifies installation and reduces wiring complexity, which significantly improves operational efficiency. Additionally, it supports multiple control functions simultaneously, enabling rapid response and long-term reliability even under demanding industrial conditions. Consequently, it provides a dependable and versatile solution for process control, system integration, and continuous operational performance.
Specification
| Specification | Details |
|---|---|
| Manufacturer | ABB |
| Model / Part Number | BDFC-01C |
| Module Type | Control Board (Advant OCS) |
| Functionality | Process control, signal processing, interface management, diagnostic support |
| Power Requirements | +5 VDC regulated supply; typical consumption 3.5 W |
| Input Channels | 8 digital inputs, supporting 24 V DC |
| Output Channels | 4 relay outputs, Form A, rated 120 VAC / 2 A |
| Analog I/O | 2 analog inputs (0–10 VDC), 1 analog output (0–10 VDC) |
| Communication Interface | ABB Advant OCS backplane connector, 32-bit data bus |
| Diagnostic Features | Onboard LEDs for power, status, and output signals; test points for voltage monitoring |
| Key Components | Microcontroller, relay drivers, analog-to-digital converters, fuses, protection diodes |
| Mounting Type | Rack-mounted, fits ABB Advant OCS chassis securely |
| Physical Dimensions | 15.0 cm × 12.0 cm × 6.0 cm |
| Weight | 0.85 kg |
| Operating Temperature | 0°C to +70°C standard industrial range |
| Environmental Ratings | Humidity 5–95% non-condensing; vibration 5–25 Hz compliant with ABB standards |
| Compliance | ABB Advant OCS standard, IEC 61131, CE compliance for industrial equipment |
| Packaging | Anti-static protective bag with protective foam inserts for shipment |
| Country of Origin | Sweden |
FAQ
A1: Yes, it integrates seamlessly into ABB Advant OCS backplanes for full system compatibility.
Q2: What industrial environments can this board operate in?
A2: It is designed for standard industrial temperature ranges and harsh operational conditions.
Q3: Can the board simplify system installation?
A3: Yes, its compact, robust design reduces wiring complexity and streamlines setup.
Q4: Does the board support multiple control functions?
A4: Yes, it can handle multiple control and signal processing tasks simultaneously.
Q5: Where is the BDFC-01C manufactured?
A5: The board is manufactured in Sweden under ABB quality standards.
