Overview
The Emerson KJ3231X1-BA1, also cataloged as the KJ3231X1-BA1 Isolated Input Card, operates as a dedicated hardware component for isolated field signal acquisition within the DeltaV M-Series I/O system. The module provides electrical separation between field circuits and the LocalBus interface while processing input signals through the controller network.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | KJ3231X1-BA1 |
| Brand | Emerson |
| Product Type | Isolated Input Card |
| System Platform | DeltaV M-Series Hardware |
| Origin | USA |
| Weight | 0.3 kg |
| Dimensions | 4.1 x 12.5 x 10.5 cm |
| Operating Temp | -40 deg C to +70 deg C |
| Power Consumption | Local Bus Power: 12 VDC at 350 mA |
| Hazardous Area Certification | II 3G Ex nA IIC Gc; FM12ATEX0090U; IECEx FMG 12.0035U |
| Additional Hazardous Certification | II 3G EEx nL IIC; Nemko 02ATEX431U |
| Terminal Block Key Position | C2 |
| Shock Resistance | 10 g half sine wave for 11 msec |
| Vibration Resistance | 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
| Airborne Contaminants | ISA-S71.04-1985 Class G3 |
| Relative Humidity | 5 to 95% non-condensing |
| Enclosure Rating | IP20 |
DeltaV Isolated Signal Processing Characteristics
The Emerson KJ3231X1-BA1 uses isolated input circuitry to separate field wiring conditions from the DeltaV controller communication path. Therefore, the card reduces electrical interaction between connected channels and the LocalBus system.
The module supports DeltaV M-Series I/O architectures with a 12 VDC LocalBus power requirement. In addition, the hardware design includes channel isolation characteristics for industrial process signal handling where field wiring protection is required.
The KJ3231X1-BA1 follows Emerson DeltaV installation practices for Zone 2 hazardous locations. Furthermore, the module requires terminal block key matching to maintain correct compatibility between the I/O card and connected terminal assemblies.
Frequently Asked Questions
Q: Can the KJ3231X1-BA1 be removed while system power remains energized?
A: The module cannot be removed or inserted with system power energized unless the installation area is confirmed as non-hazardous. Only one unit may be removed or inserted at a time.
Q: Does the KJ3231X1-BA1 require field calibration or user maintenance?
A: No. The unit contains no user-serviceable parts and does not require calibration. The module should not be disassembled during operation or maintenance activities.
Q: What installation consideration applies to nL hazardous area applications?
A: For nL installation, an I/O loop assessment must be completed for all energy-limited nodes before system operation.
Field Installation Guidelines
Install the KJ3231X1-BA1 according to DeltaV M-Series hardware installation procedures and hazardous area requirements.
Verify that the terminal block key position matches the I/O card configuration before insertion. Additionally, confirm that field wiring follows appropriate separation practices for signal integrity and hazardous location compliance.
Maintain proper grounding and shielding methods for connected field circuits. Route signal wiring separately from high-voltage power conductors to reduce electrical interference.
Before removal or insertion, verify area classification conditions and remove power when required by hazardous area procedures. Inspect connectors and terminal interfaces during installation to prevent mechanical damage or incorrect seating.
