Overview
The Emerson Ovation 5X00119G02, also cataloged as the 5X00119G02 RTD Input Electronic Module, operates as a dedicated hardware component for RTD resistance signal acquisition within the Emerson Ovation DCS I/O subsystem. The module converts RTD sensor resistance values into digital measurement data for controller processing.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 5X00119G02 |
| Brand | Emerson |
| Series | Ovation |
| Module Type | RTD Input Electronic Module |
| System Compatibility | Emerson Ovation Distributed Control System |
| Input Type | RTD resistance temperature input |
| Input Channels | 8 RTD input channels |
| Supported Sensors | RTD sensors such as Pt100 / Pt1000, configuration dependent |
| Signal Conversion | Analog-to-digital conversion for temperature measurement |
| Power Supply | 24 VDC |
| Power Consumption | Approx. 5 W |
| Operating Temp | -40 deg C to +70 deg C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Isolation | Channel-to-channel and system input isolation |
| Diagnostics | Sensor open/short detection and module status monitoring |
| Mounting Type | Emerson Ovation standard I/O rack installation |
| Dimensions | Not specified in available documentation |
| Weight | Approx. 0.3 kg – 1.2 kg, configuration dependent |
| Origin | USA |
Process Instrumentation Signal Interface
The Emerson Ovation 5X00119G02 interfaces with RTD field devices through resistance measurement channels. The module performs signal conditioning and digital conversion before transferring temperature data through the Ovation I/O architecture.
For Emerson process control hardware, temperature input modules are commonly configured with channel-level isolation to reduce interference between field measurement loops. The module design supports industrial instrumentation requirements including sensor fault monitoring and input status diagnostics.
Frequently Asked Questions
Q: What type of field signals does the 5X00119G02 measure?
A: The module measures resistance-based temperature signals from RTD sensors and converts the measured values into digital data for the Ovation controller.
Q: Does the module provide channel isolation for RTD inputs?
A: The module supports input isolation functions to separate field measurement channels and reduce signal interference within the I/O system.
Q: What power supply is required for the 5X00119G02?
A: The module operates from a 24 VDC control system power supply within the Ovation I/O installation environment.
Field Installation Guidelines
- Verify the Ovation I/O rack slot assignment before mounting the module.
- Confirm RTD sensor type and wiring configuration before connecting field cables.
- Maintain separation between RTD signal wiring and high-voltage power cables to reduce electrical noise.
- Connect cable shields according to site grounding practices and control system installation standards.
- Check channel diagnostics after installation before enabling normal process measurement.
