Overview
Configured for DC power conversion and distribution within the Westinghouse Ovation control platform, the Westinghouse 1X00416H01 (WH5-2FF Power Supply) provides direct electrical power conditioning for Ovation hardware assemblies.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 1X00416H01 |
| Brand | Westinghouse |
| Product Type | Ovation WH5-2FF Power Supply |
| System Platform | Westinghouse Ovation DCS |
| Origin | United States |
| Weight | 3.5 kg (7 lbs 12.0 oz) |
| Dimensions | 4.0 in x 4.0 in x 7.0 in (10.2 cm x 10.2 cm x 17.8 cm) |
| Tariff Code | 8504409540 |
| Electrical Function | Power supply conversion and distribution for Ovation control hardware |
Ovation Power Conversion and Distribution Characteristics
The 1X00416H01 WH5-2FF Power Supply provides regulated power conversion for Ovation control system components. The unit interfaces with the Ovation hardware architecture to supply required operating power for installed modules and electronic assemblies.
The power supply design supports stable DC output delivery within the control chassis environment. Moreover, installation requires verification of input power compatibility, chassis connection integrity, and grounding continuity before system energization.
The WH5-2FF assembly is configured as a field-replaceable power hardware component within Ovation Q-Line equipment. Therefore, maintenance procedures should follow the applicable Ovation hardware manuals for removal, replacement, and electrical verification.
Frequently Asked Questions
Q: Is the 1X00416H01 designed for installation in the Ovation Q-Line hardware platform?
A: Yes. The 1X00416H01 is identified as an Ovation WH5-2FF Power Supply component used within Westinghouse Ovation Q-Line hardware assemblies.
Q: Does available documentation specify the operating temperature range of this power supply?
A: No. The provided technical information does not include an operating temperature specification.
Q: What installation checks should be completed before powering the unit?
A: Verify mechanical mounting, power wiring connections, grounding continuity, and compatibility with the designated Ovation chassis configuration before operation.
Field Installation Guidelines
Install the 1X00416H01 power supply in the designated Ovation hardware location according to system installation documentation.
Confirm that the mounting position provides sufficient clearance for connector access and service operations. Inspect power terminals and mating connectors for contamination, mechanical damage, or loose contact conditions before installation.
Use appropriate industrial wiring practices, including proper cable routing, separation from high-noise power conductors, and correct grounding methods. Verify all electrical connections before applying system power.
