Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE5001 |
| Full Part Number | KJ1501X1-BA2 |
| Brand | Emerson DeltaV |
| Product Type | Power Supply Unit |
| System | DeltaV M-Series DCS |
| Input Voltage | 120/240 VAC |
| Input Frequency | 50/60 Hz |
| Backup Input | Optional 12 VDC / 24 VDC |
| System / Logic Output | +12 VDC |
| Additional Outputs | +5 VDC and +3.3 VDC, configuration dependent |
| Operating Temp | -40 deg C to +70 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Operating Humidity | 5% to 95%, non-condensing |
| Mounting | DIN rail or carrier-mounted |
DeltaV Process Control Power Architecture
The VE5001 converts its specified AC input into DC power for DeltaV system electronics and logic circuits. The primary input supports 120/240 VAC at 50/60 Hz, while the supplied data identifies optional 12 VDC / 24 VDC backup input capability.
The specified +12 VDC output supplies system and logic power. Additionally, +5 VDC and +3.3 VDC outputs may be available according to the installed configuration.
Because the unit operates within a DeltaV DCS power architecture, installers should keep power conductors separated from low-level 4-20 mA HART, FOUNDATION Fieldbus, and Profibus PA wiring. Proper cable segregation also limits unwanted electrical coupling between power and instrumentation circuits.
Frequently Asked Questions (FAQ)
Q: What input voltage does the VE5001 KJ1501X1-BA2 accept?
A: The supplied data specifies 120/240 VAC at 50/60 Hz. It also identifies optional 12 VDC / 24 VDC backup input capability.
Q: Which DC output supplies DeltaV system and logic circuits?
A: The specified system and logic output is +12 VDC. The supplied information also lists +5 VDC and +3.3 VDC options depending on configuration.
Q: Are the VE5001 dimensions and weight specified in the supplied data?
A: No. The supplied information does not provide dimensional or weight values. These parameters require confirmation from the applicable Emerson documentation.
Field Installation Guidelines
- Verify the complete KJ1501X1-BA2 identification before installation.
- Confirm the available AC supply voltage and frequency before energizing the unit.
- Isolate the electrical supply before connecting or removing wiring.
- Install the unit using the specified DIN rail or carrier arrangement.
- Maintain appropriate protective earth and grounding connections.
- Route AC power conductors separately from low-level instrumentation wiring.
- Avoid unnecessary parallel routing between power conductors and signal cables.
- Verify terminal assignments against the applicable Emerson installation documentation.
- Check the DC output condition before connecting downstream DeltaV equipment.
- Follow the site electrical code and DeltaV system installation requirements.
