Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | KJ4003X1-BH1 |
| Brand | Emerson DeltaV |
| Product Type | Vertical Extender Cable / System Cable |
| Cable Length | Approximately 1.1 m (43 in) |
| Connector Type | 22-pin male to 22-pin male |
| Operating Voltage | 12.6 VDC at 15 A |
| Maximum Voltage | 30 VDC |
| Operating Temp | -40 deg C to +70 deg C |
| Shielding | Multi-core shielded design |
| Mounting / Connection | Cable-connected DeltaV system hardware |
| Dimensions | Cable length approximately 1.1 m; other dimensions not specified |
Emerson DeltaV System Interconnection
The KJ4003X1-BH1 uses a 22-pin male-to-male connection to establish the specified electrical path between compatible DeltaV hardware assemblies. Its stated 12.6 VDC at 15 A rating defines the supplied operating condition, while the 30 VDC value represents the specified maximum voltage.
The shielded multi-core construction reduces susceptibility to electromagnetic interference along the cable path. Therefore, installers should maintain appropriate separation from high-current switching conductors and other strong electrical noise sources.
The cable should be treated as a system interconnection component rather than as an independent I/O module. Consequently, compatibility must follow the DeltaV hardware configuration and the applicable installation documentation.
Frequently Asked Questions (FAQ)
Q: What connector configuration does the KJ4003X1-BH1 use?
A: The supplied specification identifies two 22-pin male connectors.
Q: What electrical rating is specified for this cable?
A: The supplied data specifies 12.6 VDC at 15 A for normal operation and 30 VDC as the maximum voltage.
Q: Does the cable require shielding considerations during installation?
A: Yes. The cable uses a multi-core shielded construction. Route it separately from high-noise or high-current wiring and terminate shielding according to the applicable DeltaV installation practice.
Field Installation Guidelines
- Verify the KJ4003X1-BH1 part number before installation.
- Confirm that both mating interfaces accept the specified 22-pin connectors.
- Inspect connector pins for contamination, deformation, or mechanical damage before mating.
- Route the cable without excessive bending, pulling, or mechanical stress on the connectors.
- Keep the cable away from high-current switching conductors where practical.
- Maintain the shield termination arrangement specified by the DeltaV system installation documentation.
- Do not exceed the stated 30 VDC maximum voltage.
- Before energizing the connected hardware, verify connector seating and cable routing.
- Apply power only after confirming the complete system interconnection.
