Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE5001 |
| Full Model / Part Number | KJ1501X1-BA2 |
| Brand | Emerson DeltaV |
| Product Type | Power Supply Unit |
| System Platform | DeltaV M-Series DCS |
| Input Voltage | 120/240 VAC, 50/60 Hz |
| Backup Input | Optional 12 VDC / 24 VDC |
| Output Voltage | +12 VDC system/logic power |
| Additional Outputs | +5 VDC and +3.3 VDC options, configuration dependent |
| Operating Temp | -40 deg C to +70 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Operating Humidity | 5% to 95%, non-condensing |
| Mounting | DIN rail or carrier-mounted |
Process Control Power and Signal Architecture
The VE5001 supplies DC power for DeltaV system electronics and logic circuits. The specified primary input accepts 120/240 VAC at 50/60 Hz, while the supplied data also identifies optional 12 VDC / 24 VDC backup input capability.
The +12 VDC output serves system and logic power functions. Depending on the configuration, additional +5 VDC and +3.3 VDC outputs may support associated electronic circuits.
For DeltaV installations, power distribution should remain separated from 4-20 mA HART, FOUNDATION Fieldbus, and Profibus PA signal wiring. Therefore, installers should maintain appropriate cable segregation and grounding practices defined by the applicable DeltaV installation documentation.
Frequently Asked Questions (FAQ)
Q: What primary input voltage does the VE5001 support?
A: The supplied specification lists 120/240 VAC at 50/60 Hz. It also identifies optional 12 VDC / 24 VDC backup input capability.
Q: What DC output does the VE5001 provide for system logic?
A: The specified system and logic output is +12 VDC. The supplied data also lists +5 VDC and +3.3 VDC options depending on configuration.
Q: Does the supplied information specify the VE5001 dimensions or weight?
A: No. The supplied technical data does not provide specific weight or dimensional values, so these values should be confirmed from the applicable Emerson documentation.
Field Installation Guidelines
- Verify the exact VE5001 KJ1501X1-BA2 configuration before installation.
- Confirm the available AC input voltage and frequency against the installation design.
- Isolate power before wiring or removing the power supply.
- Use the specified mounting arrangement for the installed DeltaV enclosure or carrier.
- Route AC power conductors separately from low-level analog and communication wiring.
- Maintain appropriate protective earth and grounding connections according to site electrical standards.
- Avoid routing power wiring parallel to sensitive 4-20 mA, HART, Fieldbus, or communication cables where unnecessary.
- Confirm all terminal assignments against the applicable Emerson installation documentation before energization.
- After installation, verify output voltage and system power distribution before connecting dependent equipment.
