Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | SE4601T07 |
| Brand | Emerson |
| Product Type | CHARM Baseplate Assemblies |
| System Compatibility | Emerson DeltaV S-Series Electronic Marshalling |
| Origin | USA |
| Weight | Approx. 0.5 kg – 1.5 kg depending on configuration |
| Dimensions | Approx. 107 mm x 41 mm x 105 mm |
| Operating Temp | -40 deg C to +70 deg C |
| Power Consumption | CHARM Bus Power: 6.3 VDC at 4 A; Field Circuit Power: 24 VDC at 10 A |
| Assembly Function | CHARM I/O module mounting and electrical termination interface |
| Included Components | CHARM baseplate, CHARM address terminal block, 12 standard CHARM terminal blocks, baseplate identifier |
| Terminal Capacity | 12 standard CHARM terminal blocks |
| Mounting Type | DIN rail mounting |
| Wiring Connection | Screw terminal connection |
| Communication Interface | CHARM local bus |
DeltaV CHARM Signal Integration and HART Loop Compatibility
The Emerson SE4601T07 provides the physical interface between CHARM I/O modules and field wiring circuits in DeltaV Electronic Marshalling architectures. Therefore, it supports modular channel assignment by allowing individual CHARM modules to connect near field termination locations.
Additionally, the assembly supports DeltaV CHARM-based signal processing structures where different I/O types can be installed without conventional cabinet marshalling changes. Emerson process control systems can integrate analog and discrete field signals through CHARM modules while maintaining channel-level configuration flexibility.
The CHARM architecture supports process instrumentation interfaces including 4-20 mA HART loop protocol communication, FOUNDATION Fieldbus / Profibus PA connectivity through compatible DeltaV I/O modules, and channel-to-channel isolation requirements defined by the installed CHARM module type.
Frequently Asked Questions
Q: What is the primary electrical function of the Emerson SE4601T07?
A: The SE4601T07 provides the mounting structure, local bus connection, and field wiring termination interface for DeltaV CHARM I/O modules.
Q: How many CHARM terminal blocks are included in the SE4601T07 assembly?
A: The assembly includes 12 standard CHARM terminal blocks for field circuit connections.
Q: Does the SE4601T07 perform signal conversion or processing?
A: No. The SE4601T07 provides mechanical mounting and electrical interconnection functions. Signal processing is performed by the installed CHARM I/O modules.
Field Installation Guidelines
- Install the SE4601T07 on a compatible DIN rail system according to DeltaV cabinet installation requirements.
- Verify terminal block orientation before connecting field wiring.
- Maintain proper separation between signal wiring and power conductors to reduce electrical interference.
- Connect cable shields according to the site grounding standard and instrumentation design requirements.
- Confirm CHARM address terminal block settings before system commissioning.
- Inspect local bus connections before installing CHARM I/O modules.
- Ensure field circuit voltage ratings match the connected CHARM module specifications.
