Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | KJ4001X1-CK1 |
| Brand | Emerson |
| Product Type | 40-Pin Mass Termination Block |
| Spare Model | 12P0732X162 |
| Origin | Not specified |
| Weight | 0.06 kg |
| Dimensions | 8.8 x 4.1 x 4.2 cm |
| Power Consumption | Passive termination component, no external power consumption |
Process Control Signal Termination Features
The Emerson KJ4001X1-CK1 functions as a passive interface component within DeltaV I/O assemblies. It provides a 40-pin mass termination connection between field wiring and control system I/O channels.
The termination block supports organized signal routing and reduces individual point-to-point wiring complexity. Additionally, it maintains consistent electrical contact between connected field circuits and the associated DeltaV I/O hardware.
For Emerson process control platforms, termination accessories commonly support channel-level signal management for analog and discrete I/O configurations. The KJ4001X1-CK1 design focuses on physical connection integrity, wiring organization, and cabinet-level installation efficiency.
Frequently Asked Questions
Q: Is the Emerson KJ4001X1-CK1 an active electronic module?
A: No. The KJ4001X1-CK1 is a passive 40-pin mass termination block and does not contain active processing circuits or require external power.
Q: What is the main installation function of the KJ4001X1-CK1?
A: The block provides a structured termination point for connecting field wiring to compatible Emerson DeltaV I/O system components.
Q: Does the KJ4001X1-CK1 require firmware configuration?
A: No. The termination block has no firmware and does not require software configuration. System configuration applies to the connected DeltaV I/O modules.
Field Installation Guidelines
- Install the KJ4001X1-CK1 according to the Emerson DeltaV hardware installation documentation.
- Verify connector alignment before applying mechanical pressure during installation.
- Maintain proper cable routing separation between signal wiring and high-voltage power conductors.
- Confirm that field wiring labels match the corresponding I/O channel documentation.
- Ensure cable shields follow the plant grounding specification to minimize electrical interference.
- Inspect connector pins and wiring terminals for contamination or mechanical damage before commissioning.
