Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | KL2101X1-BB1 12P8775 SE6504 |
| Brand | Emerson |
| Product Type | CHARM I/O Card |
| Origin | USA |
| Weight | 0.3 kg |
| Dimensions | 3.4 x 13 x 13 cm |
| Operating Temp | -40 deg C to +70 deg C |
| Power Consumption | Input: 24 VDC at 2 A Max; Output: 6.3 VDC at 3.25 A |
| Input Power | 24 VDC at 2 A Max |
| Output Power | 6.3 VDC at 3.25 A |
| Shock Resistance | 10 g half-sine wave for 11 ms |
| Vibration Resistance | 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
| Airborne Contaminants | ISA-S71.04-1985 Airborne |
| Contaminants Class | G3 |
| Relative Humidity | 5 to 95% non-condensing |
Process Control Signal Interface Characteristics
The Emerson SE6504 CHARM I/O Card operates within the DeltaV CHARM I/O architecture to manage field signal termination and localized I/O conversion. Therefore, the module supports distributed channel implementation with direct connection between field wiring and controller-level processing.
Additionally, Emerson process I/O platforms typically apply channel-to-channel isolation methods to separate individual field circuits. This design reduces signal interference between independent measurement and control loops.
For instrument integration, DeltaV CHARM modules support common process communication environments, including 4-20 mA HART loop protocol implementations where compatible CHARM types are installed. The SE6504 hardware specification focuses on CHARM power distribution and I/O card operation within the DeltaV subsystem.
Frequently Asked Questions
Q: What is the primary function of the Emerson KL2101X1-BB1 12P8775 SE6504?
A: The module functions as a CHARM I/O Card for DeltaV systems, providing physical I/O interface capability between field wiring and the control system.
Q: What power input does the SE6504 require?
A: The module requires a 24 VDC input supply with a maximum input current rating of 2 A.
Q: What environmental conditions are specified for the SE6504 installation?
A: The module supports an operating temperature range from -40 deg C to +70 deg C, relative humidity from 5 to 95% non-condensing, and G3 contaminant classification.
Field Installation Guidelines
- Install the CHARM I/O Card in the designated DeltaV CHARM baseplate position according to system hardware configuration requirements.
- Verify that the 24 VDC power supply wiring polarity matches the module terminal assignment before energizing the system.
- Separate field signal wiring from high-voltage power cables to reduce electromagnetic interference.
- Maintain proper grounding and shielding practices for connected instrumentation circuits.
- Confirm environmental conditions before installation, including temperature, humidity, vibration, and airborne contaminant levels.
- Inspect connectors and terminal interfaces for mechanical damage before module insertion.
