Overview
Suffix Breakdown & Model Matrix
The supplied documentation identifies 135799-02 as a display assembly option for the 3500/93 system display. No additional suffix allocation is specified in the available data.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 3500/93 135799-02 |
| Brand | Bently Nevada |
| Product Type | Display Interface Module |
| Product Class | 3500 System Display |
| Product Family | Bently Nevada 3500 Machinery Protection Systems |
| Display Type | Color LCD system display |
| Rack Data | All 3500 monitor channels |
| Event Lists | System event list and alarm event list |
| Configuration | 3500 Rack Configuration Software |
| Communication | Display interface module link |
| Mounting Options | Face, rack, panel, or independent mounting |
| Rack Compatibility | Full-size 3500 rack |
| API Compliance | API 670 display requirements |
| Screen Supply | External display power supply |
| Power Consumption | External display power required; exact value not specified |
Rotor Dynamics Data Visualization and Alarm Management
Within the 3500 machinery protection architecture, the 3500/93 display interface module serves as the local visualization endpoint for vibration, position, speed, and process variables collected by installed monitors. The display itself does not perform eddy-current probe scaling, gap voltage validation, or signal conditioning. These functions remain in the associated monitor modules.
When connected to monitors supporting shaft displacement or vibration measurements, the display presents processed values, alarm states, and event records associated with rotor dynamics behavior. System and alarm event lists allow operators to review status changes without direct access to the rack configuration software.
Frequently Asked Questions
Q: Can the 3500/93 display interface module operate without a dedicated power source?
A: No. The display assembly requires an external display power supply as specified by the system installation documentation.
Q: Does the 3500/93 process vibration or probe signals directly?
A: No. Signal conditioning, probe scaling, gap voltage verification, and alarm calculations are executed by the installed 3500 monitor modules. The 3500/93 functions as a display and operator interface device.
Q: Is the module compatible with all 3500 racks?
A: The supplied documentation specifies compatibility with full-size Bently Nevada 3500 racks. Installation should follow rack configuration and display interface requirements defined in the system manuals.
Field Installation Guidelines
- Install the display assembly according to the selected mounting method: face, rack, panel, or independent installation.
- Route display communication wiring separately from high-energy power cables to minimize electromagnetic interference.
- Connect display cable shields to the designated grounding point defined by the 3500 installation manual.
- Verify external display power before energizing the system.
- Confirm rack communication and display operation after loading configuration data using 3500 Rack Configuration Software.
- Maintain unobstructed viewing access to alarm indications and operator controls when selecting installation locations.
