Overview
The 5X00502G01 from Emerson Ovation provides accurate analog output control for industrial automation systems. Moreover, it integrates seamlessly with Ovation distributed control architectures, enabling precise regulation of connected devices. Its compact dimensions of 160 mm × 120 mm × 75 mm optimize panel space, while the 1.2 kg weight ensures easy installation and handling.
In addition, the 5X00502G01 supports eight independent 4–20 mA output channels, offering high-resolution signal conversion for controlling valves, actuators, or other field devices. Furthermore, robust internal circuitry ensures minimal signal noise and consistent output even under varying load conditions. The module connects directly to the Ovation backplane, simplifying system integration.
Specification
| Parameter | Specification |
|---|---|
| Model | 5X00502G01 |
| Manufacturer | Emerson Ovation |
| Category | Analog Output Module |
| Series | Ovation I/O Modules |
| Dimensions (L×W×H) | 160 mm × 120 mm × 75 mm |
| Weight | 1.2 kg |
| Output Channels | 8 analog output channels |
| Output Signal Range | 4–20 mA standard |
| Output Resolution | 16-bit high-resolution DAC |
| Accuracy | ±0.1% of full scale |
| Load Impedance | 500 Ω maximum per channel |
| Update Rate | Up to 10 updates per second per channel |
| Power Supply | 24 VDC ±10% |
| Power Consumption | Typical 4 W, Maximum 6 W |
| Interfaces | Backplane bus interface for Ovation system integration |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Energy Storage | Internal capacitors for transient stabilization |
| Mounting | DIN rail or Ovation rack mounting |
| Components Included | DAC circuits, output drivers, interface controller |
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Protection Class | IP20 |
| EMC Compliance | Meets industrial EMI/EMC standards |
FAQ
Q1: Is this product brand new and original?
A1: Yes, the 5X00502G01 is 100% brand new and original Emerson Ovation module.
Q2: Do you have this module in stock?
A2: Yes, the 5X00502G01 is available in stock for immediate shipment.
Q3: How fast can the product be shipped?
A3: We ship within 3 days to 2 weeks depending on order size and availability.
Q4: Which logistics services are used?
A4: We commonly use DHL and other reliable carriers for global delivery.
Q5: What if there is a quality issue?
A5: We support returns within 30 days if any quality problem occurs.
