Overview
Specification
| Feature | Details |
|---|---|
| Product Type | PCMCIA Communication Card (Type III) |
| Compatible Platforms | Modicon Premium, Atrium Co-processor, TSX37-21/22, TSXSCY21601 |
| Protocols Supported | Modbus, Uni-Telway, Character Mode |
| Physical Interface | RS485 |
| Current Consumption | 150 mA at 5 V DC |
| Weight | 0.105 kg (0.231 lb) |
| Dimensions | 35 mm (W) x 155 mm (H) x 170 mm (D) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| RoHS Compliance | Yes (Green Premium product) |
| End-of-Service Date | December 31, 2027 |
| Warranty Period | 18 months |
FAQ
A1: The TSXSCP114 supports Modbus, Uni-Telway, and Character Mode protocols.
Q2: Which devices are compatible with the TSXSCP114?
A2: It is compatible with Modicon Premium processors, Atrium Co-processors, TSX37-21/22, and TSXSCY21601 modules.
Q3: What is the power consumption of the TSXSCP114?
A3: The card operates at 150 mA with a 5 V DC supply.
Q4: Is the TSXSCP114 compliant with environmental standards?
A4: Yes, it is RoHS compliant and is part of Schneider Electric’s Green Premium product line.
Q5: What is the warranty period for the TSXSCP114?
A5: The product comes with an 18-month warranty.
