Overview
Specification
| Category | Specification |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product Type | DC discrete output module |
| Discrete Outputs | 16 outputs |
| Output Voltage Limits | 10…60 V DC |
| Output Current | 0.5 A per channel (max) |
| Output Delay | ≤ 1 ms |
| Switching Frequency | ≤ 1 kHz resistive load |
| Isolation (Group/Bus) | 2500 Vrms for 1 min |
| Isolation (Between Groups) | 700 Vrms for 1 min |
| Power Dissipation | 4 W + (1.2 × number of outputs ON) |
| Bus Current Requirement | 250 mA |
| Local Signaling | 1 LED green: bus active1 LED red: external fault16 green LEDs: output status |
| Module Format | Standard Quantum rack |
| Net Weight | 0.34 kg |
| Operating Temperature | 0…60 °C |
| Storage Temperature | -40…85 °C |
| Relative Humidity | 95% non-condensing |
| Operating Altitude | ≤ 5000 m |
| Standards | UL 508, CSA C22.2 No 142 |
| Certifications | FM Class 1 Division 2, CE, C-Tick |
FAQ
A: Yes, 140DDO35300 integrates seamlessly with Quantum automation platforms.
Q: What is the delivery time for this module?
A: All units are brand new and shipped within 3 days to 2 weeks, depending on order size.
Q: How is it protected against voltage issues?
A: The module features transil diode overvoltage protection and automatic trip for overloads.
Q: Can I return the product if there’s a defect?
A: Yes, we support returns within 30 days for quality issues.
Q: What is the maximum current per output channel?
A: Each channel supports up to 0.1 A, with a total module current of 3.2 A.
