Overview
The Schneider Electric Foxboro FBM217 serves as a high-density discrete input interface within the I/A Series Distributed Control System. This robust module, identified by part number RH914TR, features 32 discrete input channels designed for demanding industrial environments. It provides reliable signal monitoring by mounting onto a modular baseplate or a 100 Series conversion structure. Furthermore, the FBM217 supports redundancy when you pair two units with the RH926ZY redundancy adapter in adjacent baseplate slots.
Specification
| Parameter | Specification |
|---|---|
| Module Compatibility | FBM217 Discrete Input Module |
| Mounting Method | Modular baseplate, DIN rail, or 19-inch rack mounting |
| DIN Rail Support | 32 mm (1.26 in) and 35 mm (1.38 in) rails |
| Redundancy Installation | Adjacent slots (1–2, 3–4, 5–6, 7–8) with redundancy adapter |
| Conversion Mounting Option | 100 Series conversion mounting structure (non-redundant) |
| Approximate Weight | 284 g (10 oz) |
| Weight (Compression Versions) | 420 g (0.93 lb) at 216 mm; 454 g (1.0 lb) at 233 mm |
| Height | 102 mm (4 in), 114 mm (4.5 in) including mounting lugs |
| Width | 45 mm (1.75 in) |
| Depth | 104 mm (4.11 in) |
| Cable Length | Up to 30 m (98 ft) |
| Cable Material | Polyurethane or Low Smoke Zero Halogen (LSZH) |
| Termination Cable Type | Type 4 (Baseplate to TA), Type 6 (Main TA to Expansion TA) |
| Cable Connector Type (Type 4) | 37-pin D-sub plug (baseplate), 37-pin D-sub receptacle (TA) |
| Cable Connector Type (Type 6) | 25-pin D-sub (main TA), 37-pin D-sub (expansion TA) |
| Construction Material | Polyamide (PA), compression type |
| Field Wiring Type | Compression terminal |
| Wiring Size (Solid/Stranded) | 0.2 to 4 mm² / 24 to 12 AWG |
| Wiring Size (Ferrules) | 0.2 to 2.5 mm² with or without plastic collar |
| Termination Style | Compression screw terminals |
| Part Number (Module) | RH914TR |
| Part Number (Redundancy Adapter) | RH926ZY |
| Installation Orientation | Horizontal or vertical DIN rail mounting |
| Expansion Capability | Supports expansion termination assemblies via Type 6 cable |
