Overview
The FBM202 input module provides accurate signal acquisition for Foxboro I/A Series distributed control systems.
It processes analog input signals efficiently while ensuring stable and consistent data transmission in industrial environments.
Moreover, FBM202 integrates with modular baseplates, which enables flexible installation and scalable system configurations.
Its compact mechanical design improves cabinet space utilization while supporting long-term operation in harsh conditions.
Specification
| Parameter | Specification |
|---|---|
| Model | FBM202 |
| Manufacturer | Foxboro (Schneider Electric) |
| Series | I/A Series 200 |
| Module Type | Analog Input Module |
| Mounting (Module) | Baseplate or 100 Series conversion structure |
| Mounting (Baseplate) | DIN rail (horizontal/vertical) or 19-inch rack |
| Mounting (TA) | DIN rail or baseplate-mounted |
| Weight (Module) | Approx. 284 g (10 oz) |
| Weight (TA DIN Rail) | Approx. 159 g (0.35 lb) |
| Weight (TA Baseplate) | Approx. 245 g (0.57 lb) |
| Weight (TA Ring Lug) | Approx. 204 g (0.45 lb) |
| Dimensions (Height) | 102 mm (4 in), 114 mm (4.5 in with lugs) |
| Dimensions (Width) | 45 mm (1.75 in) |
| Dimensions (Depth) | 104 mm (4.11 in) |
| Module Part Number | RH926EQ (supersedes P0926EQ) |
| Cable Length | Up to 30 m (98 ft) |
| Cable Material | Polyurethane or LSZH |
| Cable Type | Type 2 |
| Connector Type | 37-pin D-sub (baseplate), 25-pin D-sub (TA) |
| TA Material (DIN Rail) | Polyamide (PA), compression and ring lug |
| TA Material (Baseplate) | PC/ABS, compression |
| Wiring Type | Compression and ring lug |
| Wiring Size (DIN Rail TA) | 0.2 to 4 mm² / 24 to 12 AWG |
| Wiring Size (Baseplate TA) | 0.2 to 1.5 mm² / 24 to 16 AWG |
| Wiring Size (Ferrules) | 0.25 to 1.5 mm² depending on collar usage |
| Ring Lug Wiring Size | 0.5 to 4 mm² / 22 to 12 AWG |
FAQ
Q1: What type of signals does FBM202 handle?
The FBM202 processes analog input signals for industrial monitoring and control applications.
Q2: What cable type works with FBM202?
The FBM202 uses Type 2 termination cables for stable communication between baseplate and assemblies.
Q3: What mounting options does FBM202 support?
The FBM202 supports DIN rail, rack mounting, and 100 Series conversion structures for flexible installation.
Q4: What is the delivery and stock status?
This product is brand new and original, and we keep stock available for immediate shipment.
Q5: How fast can shipping be arranged?
We usually ship within 3 days to 2 weeks, depending on order size and logistics such as DHL.
Q6: What happens if there is a quality issue?
