Overview
The Emerson EPRO CON021/913-040, also cataloged as the CON021 Signal Converter, operates as a dedicated hardware component for eddy current displacement signal conditioning within EPRO machinery protection measurement systems. It processes probe oscillator signals from PR6423 series sensors and provides proportional electrical outputs for vibration and position monitoring circuits.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CON021/913-040 |
| Brand | Emerson EPRO |
| Origin | Germany |
| Operating Temp | -30 deg C to +100 deg C |
| Power Consumption | Not specified in available data |
| Measurement Principle | Eddy current displacement signal conversion |
| Compatible Sensor | PR6423 series eddy current probes |
| Supply Voltage Range | -23 VDC to -32 VDC |
| Output Signal | Buffered AC vibration signal and proportional DC output |
| Mounting Type | DIN-rail or panel mounting configuration |
| Protection Class | IP65 when installed in a suitable enclosure |
Eddy Current Measurement Signal Processing
The Emerson EPRO CON021/913-040 operates within an eddy current measurement chain consisting of a sensor probe, extension cable, and signal converter. The converter supplies the probe excitation signal, demodulates the returned high-frequency response, and generates conditioned outputs representing shaft displacement or vibration movement.
For machinery monitoring applications, signal scaling depends on the connected PR6423 probe characteristics, including probe sensitivity, target material properties, and calibrated measurement gap. Proper gap voltage validation is required during commissioning to confirm the sensor operates within the specified linear measurement range.
The signal chain design supports rotor dynamics analysis by maintaining the relationship between shaft movement and electrical output. Shielded cable routing and correct grounding practices are required to minimize external electromagnetic interference and measurement signal distortion.
Frequently Asked Questions
Q: What type of sensor does the CON021/913-040 connect to?
A: The CON021/913-040 is designed for connection with compatible EPRO eddy current proximity probes, including PR6423 series sensors. The complete measurement chain requires the matched probe, cable, and converter configuration.
Q: Does the CON021/913-040 provide direct vibration analysis signals?
A: The converter provides conditioned output signals, including buffered AC vibration-related signals, which can be connected to machinery monitoring or protection systems for further analysis.
Q: What installation factors affect measurement accuracy?
A: Probe gap adjustment, cable shielding, grounding method, and correct sensor-converter matching affect the electrical measurement performance of the eddy current system.
Field Installation Guidelines
Install the CON021/913-040 in a cabinet location with appropriate environmental protection and maintain separation between sensor signal wiring and high-current power cables.
Connect the eddy current probe using the specified cable arrangement and verify cable shielding continuity according to the machinery monitoring system grounding practice. Avoid parallel routing with sources of electromagnetic interference such as motor feeders and switching devices.
During commissioning, verify probe gap conditions, converter supply voltage, and output signal behavior before connecting the channel to the final protection or monitoring logic. The complete probe-converter chain should be checked as a calibrated measurement system rather than evaluating the converter independently.
