Emerson DeltaV SE3007 SX Controller

Hardware Specifications

DeltaV DCS Process Control Interface

The Emerson SE3007 SX Controller provides local bus control processing for DeltaV system architectures. It manages controller-level communication and execution functions through the Emerson control network structure.

Additionally, the module supports deterministic local bus operation with a defined +5 VDC power requirement. The controller design allows integration within DeltaV hardware assemblies while maintaining specified environmental operating limits.

For Emerson process control platforms, controller modules typically operate with coordinated I/O communication paths. Therefore, proper configuration of the local bus interface, grounding arrangement, and module addressing is required during installation.

Frequently Asked Questions

Q: What power input does the Emerson SE3007 require?
A: The SE3007 requires +5 VDC local bus power with a current consumption of 1.4 A.

Q: What environmental conditions support SE3007 operation?
A: The module supports an ambient temperature range from -40 deg C to +60 deg C, with 5 to 95% non-condensing relative humidity.

Q: Is the SE3007 designed for DeltaV system integration?
A: Yes. The SE3007 is an SX Controller module designed for Emerson DeltaV control system hardware configurations.

Field Installation Guidelines

Install the SE3007 module in the designated Emerson DeltaV hardware carrier or controller assembly according to system engineering documentation.

Verify that the local bus power supply provides the specified +5 VDC input before module installation. Use proper cabinet grounding practices and separate controller wiring from high-voltage power cables to reduce electrical interference.

Confirm that environmental conditions remain within the specified temperature, humidity, airborne contaminant, and shock limits. Inspect connector seating and module locking mechanisms before system commissioning.
