Overview
The Honeywell CC-UPTA01 functions as a single-channel Universal Pass Through Adapter, enabling seamless connectivity between Safety System or Safety field terminals and field devices. It allows direct connections without using external power, making it ideal for applications with limited power availability or where external power sources are undesirable.
The CC-UPTA01 connects DCS field terminals, both live and return, directly to field devices. It operates independently of external power and works efficiently with the CC-USCA01 module, ensuring reliable signal transmission in safety and control applications.
Specification
• Single channel Pass Through Adapter
• 2 wire AI/AO/DI/DO
• System powered field I/O
• HART Pass Through
• Interface with conventional Series C IOMs and Universal Input Output Module
| Feature | Specification |
|---|---|
| Power Supply | 24V DC |
| Maximum Current | 500 mA |
| Field Side Interface | Dedicated 3 terminals per channel |
| Wire Gauge Range | 12–24 AWG |
| Safety System Interface | 37-pin DSUB (for SIC cable) |
| Dimensions | 118 mm (D) x 85.75 mm (W) x 10.0 mm (H) |
| Mounting | Base plate with DIN rail mount and snap housing |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Compliance | RoHS, IECEx, ATEX, cCSAus |
Manual/Datasheet PDF
CC-UPTA01 Honeywell C300 Universal Pass Through Adapter datasheet
