Overview
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 176499-02 |
| Brand | Bently Nevada |
| Product Type | Thrust Monitor Module |
| System Series | 3500 |
| Thrust Range | 0-200 kN |
| Accuracy | +/- 0.5% of full scale |
| Resolution | 0.1 kN |
| Operating Temperature | -40 to +85 deg C |
| Weight | 0.5 kg |
| Dimensions | 100 x 100 x 50 mm |
Thrust Monitoring Function
Thrust monitoring tracks axial shaft movement relative to a reference point. As a result, operators can use these measurements to assess changes in machine position and compare them with configured alarm limits. The actual measurement depends on the installed transducer, signal conditioning, and monitor configuration.
Configuration and Selection
Before selecting the 176499-02 as a replacement, check the complete part number against the installed hardware and equipment records. Also, verify the required monitor function, sensor input arrangement, and rack configuration. These checks help prevent a mismatch between the replacement module and the existing monitoring system.
Frequently Asked Questions
Q: What does the Bently Nevada 176499-02 monitor?
A: The supplied information identifies it as a thrust monitor module for machinery monitoring. Confirm its exact function and supported sensor arrangement before installation.
Q: What accuracy and resolution does the 176499-02 specify?
A: The supplied data lists an accuracy of +/- 0.5% of full scale and a resolution of 0.1 kN. However, verify both values against technical documentation for this exact model before using them in measurement calculations.
Q: Can the 176499-02 replace another 3500 Series module?
A: Not based on the series name alone. Instead, compare the full part number, monitor function, transducer requirements, and rack configuration before approving a replacement.
