AMM31 Yokogawa Analog Input / Multiplexer Module

Hardware Specifications

Yokogawa DCS Signal Interface Characteristics

The AMM31 processes analog field inputs through Yokogawa DCS signal acquisition architecture. It supports measurement channels connected to temperature, pressure, flow, and level instruments. In addition, the module performs signal conditioning before transferring converted values to the CENTUM control network.

For process instrumentation applications, the AMM31 supports Yokogawa-specific analog handling methods, including channel-to-channel isolation and cold junction compensation (CJC) functions when configured for thermocouple input processing. Therefore, the module maintains signal separation between field circuits and the control system electronics.

The module can interface with conventional 4-20 mA HART loop protocol environments through compatible system configurations. Furthermore, FOUNDATION Fieldbus and Profibus PA field devices can be integrated through dedicated Yokogawa communication modules within the overall DCS architecture.

Frequently Asked Questions

Q: Does the Yokogawa AMM31 support direct connection of all analog transmitter types?
A: The AMM31 supports configured analog input types defined by the installed Yokogawa system configuration. Field devices must match the module input specification and terminal arrangement.

Q: Does the AMM31 provide electrical isolation between field signals and the DCS system?
A: Yes. The module provides channel-to-ground and channel-to-system isolation functions to reduce interference caused by industrial grounding conditions.

Q: Can the AMM31 be replaced while the DCS system is operating?
A: Hot-swap operation depends on the specific CENTUM hardware configuration and rack design. Maintenance personnel must verify system replacement procedures before removing the module.

Field Installation Guidelines

• Install the AMM31 in the designated Yokogawa DCS rack slot according to the system hardware manual.
• Verify that field wiring matches the configured input signal type before terminal connection.
• Use shielded instrumentation cables for low-level analog signals to reduce electromagnetic interference.
• Connect cable shields according to Yokogawa grounding recommendations and avoid multiple grounding points.
• Separate analog signal wiring from high-voltage power cables and switching circuits.
• Confirm backplane seating and connector engagement before system startup.
• Verify channel configuration, input scaling, and engineering units through the CENTUM engineering station.
