Overview
Engineers benefit from its compact size and direct integration with Modicon Premium PLCs, making installation efficient without compromising performance. The TSXAEY1600 supports a reliable 270 mA current consumption at 5 V DC, ensuring stable operation even under demanding conditions.
Specification
| Category | Specification |
|---|---|
| Range of Product | Modicon Premium |
| Product Type | Analog Input Module |
| Analog Input Channels | 16 high-level inputs |
| Resolution | 12-bit conversion |
| Rated Supply Voltage | 5 V DC |
| Current Consumption | 270 mA |
| Conversion Time | 2 ms |
| Input Type | Differential |
| Input Voltage Range | ±10 V |
| Isolation | 500 V AC between channels and logic |
| Diagnostics | Channel status LEDs |
| Protective Features | Internal protection against polarity reversal and surges |
| Dimensions (H x W x D) | 125 x 32 x 110 mm |
| Net Weight | 0.25 kg |
| Certifications | CE, UL, CSA |
| Operating Temperature | 0…60 °C |
| Storage Temperature | -40…85 °C |
| Relative Humidity | 5…95 % without condensation |
| Operating Altitude | ≤ 2000 m (derating required above 2000 m) |
FAQ
Yes, we supply brand-new and factory-sealed Schneider TSXAEY1600 analog input modules.
Q2: How many channels does the TSXAEY1600 provide?
It offers 16 high-level differential analog input channels with 12-bit resolution.
Q3: What is the power requirement for this module?
The module operates at 5 V DC with a current consumption of 270 mA.
Q4: How fast is the conversion time?
The module performs analog-to-digital conversion in approximately 2 milliseconds.
Q5: What are your shipping and return policies?
We ship within 3 days to 2 weeks depending on order size, typically via DHL. If quality issues arise, we support returns within 30 days.
