Overview
NFDR541-P00 from YOKOGAWA provides dependable relay-based output control for industrial automation systems.
Moreover, the module enables direct switching of field devices such as motors, alarms, and solenoids.
Engineers choose NFDR541-P00 to achieve robust on/off control with electrical isolation and durability.
Additionally, the module integrates efficiently with CENTUM CS and CENTUM VP control system platforms.
Therefore, users maintain stable output control while improving system safety and operational reliability.
Specification
| Parameter | Specification |
|---|---|
| Model | NFDR541-P00 |
| Manufacturer | YOKOGAWA |
| Module Type | Relay Output Module |
| Output Channels | 16 channels |
| Output Type | Electromechanical relay contacts |
| Contact Configuration | Normally open (NO) contacts |
| Rated Load Voltage | 24 V DC / 120 V AC typical |
| Maximum Switching Voltage | Up to 250 V AC |
| Maximum Switching Current | Approx. 2 A per channel |
| Contact Life | Mechanical: >10 million operations (typical) |
| Electrical Life | Depends on load conditions |
| Response Time | Approx. 10 ms to 20 ms |
| Isolation Method | Relay isolation between control and output circuits |
| Surge Suppression | Built-in suppression components |
| Power Supply | Supplied via base unit |
| Power Consumption | Approx. 4 W |
| Energy Storage | Internal capacitors for transient stabilization |
| Interface Type | Terminal block for field wiring |
| Mounting Method | Rack-mounted installation |
| Slot Requirement | Single slot |
| Dimensions (W × H × D) | Approx. 32 × 130 × 107 mm |
| Weight | Approx. 0.4 kg |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 75°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| EMC Compliance | Meets industrial EMC standards |
| Cooling Method | Natural convection |
FAQ
Q1: How many output channels does NFDR541-P00 provide?
A1: NFDR541-P00 provides 16 relay output channels for industrial control applications.
Q2: What type of output does the module use?
A2: The module uses electromechanical relay contacts with normally open configuration.
Q3: What load can each relay channel handle?
A3: Each channel supports up to approximately 2 A with typical industrial voltage ratings.
Q4: What is the product condition and stock availability?
A4: The product is brand new original, in stock, and ready for shipment.
Q5: How long does shipping take?
A5: We ship within 3 days to 2 weeks depending on order size.
Q6: Which logistics services do you use?
A6: We commonly use DHL and other reliable international logistics providers.
