Overview
The GE DS200LDCCG1ADA, associated with the DS200LDCCG1A base model designation, is described as a drive control board for GE industrial control hardware. The supplied information identifies LAN communication and drive control functions, but does not confirm the exact communication protocols, processing architecture, or supported system configurations. Verify the board revision and equipment compatibility before installation.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DS200LDCCG1ADA |
| Base Model | DS200LDCCG1A |
| Brand | General Electric (GE) |
| Product Series | DS200; exact system platform requires verification |
| Board Type | Drive Control Board |
| Primary Function | Drive control and communication |
| Origin | USA |
| Tariff Code | 8537101190 |
| Mounting | Control chassis installation; exact slot and mounting requirements require verification |
| Communication Interfaces | Specific ports and protocols not confirmed |
| Connectors | Exact connector types and pin assignments not provided |
Industrial Drive Control and Backplane Compatibility
Drive control boards exchange control signals and status data with other system components through their specified electrical interfaces. For the DS200LDCCG1ADA, confirm the applicable backplane connections, signal assignments, and firmware compatibility against the equipment documentation before replacing an installed board.
Do not assume compatibility with a Mark V turbine controller or EX2000 excitation system solely from the general product description. Confirm the complete board part number, revision, and host equipment configuration.
Frequently Asked Questions (FAQ)
Q: Can the DS200LDCCG1ADA be installed in a powered chassis?
A: Hot-swap capability is not confirmed by the supplied information. Isolate power according to the host equipment service procedure before removing or installing the board.
Q: Which communication protocols does this board support?
A: The supplied description references LAN communication and drive control but does not identify specific protocols, port assignments, or supported network configurations. Consult the applicable GE hardware documentation.
Q: Can the DS200LDCCG1ADA replace another DS200LDCC board?
A: Not without verification. Compare the complete part number, hardware revision, connector layout, firmware requirements, and host system compatibility before substitution.
Field Installation Guidelines
- Verify the complete part number and revision against the equipment bill of materials.
- De-energize the equipment and follow the manufacturer’s electrical isolation procedure.
- Inspect the PCB, connectors, and chassis for visible damage, contamination, or bent contacts.
- Use appropriate electrostatic discharge (ESD) protection when handling the board.
- Align the board with the designated chassis guides and connectors. Do not force insertion.
- Confirm cable routing, connector seating, and grounding arrangements against the equipment drawings.
- Restore power according to the approved commissioning procedure and check system diagnostics for faults.
