Overview
The Honeywell FC-BSN-1608 is a specialized converter designed to interface Namur sensors with standard analog input systems, ensuring safe and reliable signal conversion in industrial applications.
The Safety sensor signal converter module BSN-1608 converts sixteen Pepperl+Fuchs (P+F) Safety sensor signals to 0-8 V signals for the safe line-monitored digital input module SDIL-1608. All inputs are passive and have a common 8 V connection.
Specification
| General | Type numbers: | FS-BSN-1608 |
| FC-BSN-1608 | ||
| Approvals: | CE,TUV,UL,CSA,FM | |
| Power | Power requirements: | None |
| Analog input | Number of input channels: | 16 |
| Input current: | 0-11 mA | |
| Input resistance: | 715Ω1% | |
| Absolute max.input current: | 25 mA | |
| Cable capacitance | total of all connected cables) | <16μF 2 |
| Earth resistor | Resistance: | 100 kΩ 1%2 |
| Maximum dissipation: | 0.6W | |
| Physical | Dimensions: | 58.5×28.5×9mm(2.3×1.125×0.35 in) |
| Chassis space requirements: | None(placed on programming connector on IO backplane) |
