Overview
Moreover, the FBM204 integrates seamlessly within the Foxboro I/A Series architecture and ensures consistent signal transmission accuracy.
Additionally, this assembly supports multiple wiring configurations and improves maintenance efficiency across complex automation environments.
Therefore, engineers rely on the FBM204 for dependable connectivity and structured field device integration.
Specification
| Parameter | Detailed Specification |
|---|---|
| Model | FBM204 |
| Manufacturer | Foxboro (Schneider Electric) |
| Product Type | Field Terminal Assembly (FTA) for I/O Modules |
| Series | Foxboro I/A Series |
| Supported Module Type | Discrete Input Fieldbus Module |
| Input Channels | 16 isolated digital input channels |
| Input Signal Type | Dry contact or voltage input |
| Nominal Input Voltage | 24 V DC |
| Input Voltage Range | 15–32 V DC |
| Input Current | Approx. 2–5 mA per channel |
| Channel Isolation | Optical isolation between channels and system |
| Group Isolation | Isolated groups to prevent signal interference |
| Terminal Type | Industrial screw-type terminal blocks |
| Wiring Capacity | Supports 14–22 AWG field wiring |
| Connector Type | Backplane connector for FBM interface |
| Mounting Method | DIN rail mounting or panel mounting |
| Dimensions (H × W × D) | Approx. 200 mm × 150 mm × 60 mm |
| Weight | Approx. 0.8–1.0 kg |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration Resistance | Complies with IEC industrial vibration standards |
| Shock Resistance | Designed for industrial shock conditions |
| EMC Compliance | Meets industrial EMC standards (IEC/EN 61000 series) |
| Power Consumption | Typically less than 5 W |
| Energy Dissipation | Low thermal output for cabinet integration |
| Safety Rating | Designed for safe-area industrial environments |
| Certification | CE, UL (depending on configuration) |
| Cable Entry | Front-access terminal wiring |
| Maintenance Access | Front panel access for easy inspection and replacement |
| Redundancy Support | Compatible with redundant system architectures |
| Signal Status Indication | LED indicators per channel for status monitoring |
| Installation Environment | Suitable for control cabinets in industrial automation systems |
FAQ
Q1: Is the FBM204 a brand-new original product?
A1: Yes, the FBM204 is brand new and original from the manufacturer.
Q2: Do you have the FBM204 in stock?
A2: Yes, we keep the FBM204 in stock and ready for immediate processing.
Q3: How fast can you ship the FBM204?
A3: We ship the FBM204 within 3 days to 2 weeks depending on order quantity.
Q4: What logistics services do you use for delivery?
A4: We usually ship the FBM204 via DHL and other major international carriers.
Q5: What is the input voltage range of the FBM204?
A5: The FBM204 typically supports 24 V DC digital input signals for industrial applications.
Q6: Do you support returns if there is a quality issue?
A6: Yes, we support returns of the FBM204 within 30 days if any quality problem occurs.
