Overview
F3XD16-3F from YOKOGAWA delivers precise DC signal acquisition for industrial automation and control systems.
Moreover, the module supports 16 discrete input channels for efficient field signal integration.
Engineers rely on F3XD16-3F to monitor digital signals from sensors and switching devices accurately.
Additionally, the compact structure simplifies installation inside high-density control cabinets.
Therefore, users improve system responsiveness while maintaining stable and noise-resistant signal processing.
Specification
| Parameter | Specification |
|---|---|
| Model | F3XD16-3F |
| Manufacturer | YOKOGAWA |
| Module Type | DC Digital Input Module |
| Number of Input Channels | 16 channels |
| Input Voltage Range | 24 V DC nominal (typical industrial range 20.4–26.4 V DC) |
| Input Current | Approx. 5–7 mA per channel |
| Input Type | Sink/Source compatible (depending on wiring configuration) |
| Signal Level Detection | ON ≥ 19 V DC, OFF ≤ 5 V DC |
| Response Time | Approx. 5 ms to 10 ms |
| Isolation Method | Optical isolation between input and internal logic |
| Withstand Voltage | Meets industrial isolation standards |
| Input Filtering | Built-in digital filter for noise suppression |
| Power Supply | Supplied via base unit backplane |
| Current Consumption | Approx. 0.2–0.4 A |
| Connector Type | Dedicated terminal block or cable interface |
| Wiring Method | Field wiring via terminal module |
| Mounting Method | Rack-mounted on Yokogawa base unit |
| Slot Requirement | Single slot |
| Dimensions (W × H × D) | Approx. 32 × 130 × 107 mm |
| Weight | Approx. 0.3 kg |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 75°C |
| Relative Humidity | 5% to 95% RH (non-condensing) |
| Vibration Resistance | Complies with industrial vibration standards |
| Shock Resistance | Designed for industrial shock environments |
| EMC Compliance | Meets industrial EMC immunity and emission standards |
FAQ
Q1: How many input channels does F3XD16-3F provide?
A1: F3XD16-3F provides 16 DC input channels for industrial signal monitoring applications.
Q2: What input voltage does the module support?
A2: The module supports 24 V DC nominal input with a typical industrial operating range.
Q3: Does F3XD16-3F include signal isolation?
A3: Yes, it uses optical isolation to protect the system from electrical interference.
Q4: What is the response time of the module?
A4: The response time ranges from approximately 5 ms to 10 ms depending on signal conditions.
Q5: What is the product condition and delivery time?
A5: The product is brand new original, in stock, and ships within 3 days to 2 weeks.
Q6: Which shipping services do you use?
A6: We commonly use DHL and other reliable international logistics providers.
