Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE4002S1T2B5 |
| Brand | Emerson |
| Product Type | Analog Output Module |
| System Platform | Emerson DeltaV Distributed Control System |
| Origin | USA |
| Weight | 0.18 kg |
| Dimensions | 4.1 x 12.5 x 10.5 cm |
| Operating Temp | -40 deg C to +70 deg C |
| Power Consumption | Local Bus Power: 12 VDC at 150 mA |
| Field Power Supply | Bussed Field Power: 24 VDC at 3.2 A per card |
| Field Circuit Load | 24 VDC at 100 mA per channel |
| Shock Resistance | 10 g half-sine wave for 11 ms |
| Vibration Resistance | 1 mm peak-to-peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
| Airborne Contaminants | ISA-S71.04-1985 Airborne Contaminants Class G3 |
DeltaV Analog Signal Output Characteristics
The Emerson VE4002S1T2B5 operates as a DeltaV analog output interface module for transmitting control signals from the controller layer to connected field devices. It uses the DeltaV I/O architecture to process output commands and provide electrical drive capability through field circuits.
Additionally, the module supports Emerson process control environments where analog output channels require controlled current transmission and field power distribution. The hardware design includes local bus power consumption management and dedicated field power routing.
For Emerson DeltaV installations, analog signal integrity depends on correct loop wiring, grounding practices, and channel isolation configuration. The module should be integrated with compatible DeltaV controllers, carriers, and terminal assemblies.
Frequently Asked Questions
Q: What power sources does the VE4002S1T2B5 require?
A: The module requires 12 VDC local bus power at 150 mA and uses 24 VDC bussed field power at 3.2 A per card.
Q: What environmental conditions support VE4002S1T2B5 operation?
A: The module supports an operating temperature range from -40 deg C to +70 deg C and meets ISA-S71.04-1985 Class G3 airborne contaminant requirements.
Q: What installation factors affect analog output performance?
A: Proper field wiring, signal cable separation, grounding practices, and correct DeltaV carrier installation affect analog output signal performance.
Field Installation Guidelines
- Install the VE4002S1T2B5 on the designated Emerson DeltaV carrier assembly according to system hardware documentation.
- Verify local bus power availability before module insertion.
- Separate analog signal wiring from high-voltage switching cables to reduce electrical interference.
- Connect field wiring with correct polarity and verify terminal assignments before energizing circuits.
- Apply proper shield grounding methods according to site electrical standards.
- Confirm controller configuration and I/O assignment before placing the output channels into service.
