Overview
This Modicon X80 output module ensures excellent reliability, delivering fast response times and consistent performance across industrial environments. With its modular architecture, engineers can integrate the BMXDDO3202K seamlessly into X80 racks while maintaining system flexibility and scalability.
Specification
| Category | Specification |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Discrete Output Module |
| Output Channels | 32 transistor outputs |
| Logic Type | Positive |
| Rated Supply Voltage | 24 V DC |
| Output Voltage Range | 19.2…28.8 V DC |
| Max Current per Channel | 0.5 A |
| Total Current per Module | 16 A |
| Maximum Dissipation | 10.5 W |
| Electrical Isolation | 500 V AC between channels and bus |
| Switching Frequency | 1 kHz resistive load |
| Diagnostics | Output status LEDs, error indication |
| Protective Features | Electronic protection against overloads and short circuits |
| Connection Type | 40-pin removable terminal block |
| Dimensions (H x W x D) | 32 x 100 x 86 mm |
| Net Weight | 0.16 kg (0.35 lb) |
| Certifications | CE, UL, CSA, FM Class 1 Division 2 |
| Operating Temperature | 0…60 °C |
| Storage Temperature | -40…85 °C |
| Relative Humidity | 5…95 % without condensation |
| Operating Altitude | ≤ 2000 m (up to 5000 m with derating) |
FAQ
Yes, we only supply brand-new and factory-sealed Schneider Modicon X80 BMXDDO3202K modules.
Q2: How quickly can you deliver this module?
We usually ship within 3 days to 2 weeks depending on order size, using DHL or similar carriers.
Q3: How many outputs does the BMXDDO3202K provide?
It features 32 transistor outputs designed for 24 V DC positive logic.
Q4: Does the module have short-circuit protection?
Yes, it includes built-in electronic protection against overloads and short circuits.
Q5: What is the size and weight of the BMXDDO3202K?
It measures 32 x 100 x 86 mm and weighs 0.16 kg, making installation simple and space-efficient.
