Overview
The AO3481 Triconex Analog Output Module converts digital signals from Tricon controllers into precise analog outputs. Its robust design guarantees consistent performance in industrial environments, including temperature extremes and vibration. The module integrates seamlessly with Tricon series chassis and complements safety-critical systems.
Specification
| Parameter | Specification |
|---|---|
| Model | AO3481 |
| Manufacturer | Triconex / Invensys |
| Module Type | Analog Output Module |
| Output Channels | 16 channels (configurable) |
| Output Signal Range | 0–20 mA, ±10 V |
| Output Load | 600 Ω max (current mode), 1 kΩ min (voltage mode) |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Response Time | <10 ms per channel |
| Isolation | 2500 V galvanic isolation between outputs and backplane |
| Diagnostics | Open-circuit, short-circuit, and module fault detection |
| Power Supply | 24 VDC internal distribution |
| Power Consumption | 4 W typical |
| Internal Components | Precision DACs, decoupling capacitors, microcontroller for signal control |
| Backplane Interface | Standard Tricon backplane connector |
| Dimensions | 180 mm × 80 mm × 35 mm |
| Weight | 1.0 kg |
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% RH non-condensing |
| Vibration Tolerance | 5–25 Hz: 2g; 25–100 Hz: 0.5g |
| Signal Slew Rate | 1 V/ms typical |
| Noise Level | <0.05% of full scale |
| Certification | CE, UL listed (industrial safety standard) |
FAQ
Q1: Is the AO3481 module new and original?
A1: Yes, all our AO3481 modules are fully new, factory-original units.
Q2: How fast can you ship this analog output module?
A2: We ship within 3 days to 2 weeks depending on order quantity.
Q3: Which logistics companies do you use for delivery?
A3: We commonly use DHL, FedEx, and UPS for global shipments.
Q4: What if the product has a quality issue?
A4: We support returns within 30 days if quality issues arise.
Q5: How many output channels does this module support?
A5: The AO3481 supports 16 analog output channels for precise process control.
Q6: What is the response time for each output channel?
A6: Each channel responds in less than 10 ms for real-time control.
