Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 1769-PA4 |
| Brand | Allen-Bradley |
| Product Type | AC Power Supply Module |
| Product Line | CompactLogix |
| Nominal Input Voltage | 120/220 V AC |
| Input Voltage Range | 85-265 V AC or 170-265 V AC |
| User-Selectable Input Voltage | Yes |
| Power Consumption | 200 VA at 120 V AC; 240 VA at 240 V AC |
| Power Dissipation | 18 W at 60 deg C |
| Output Current at 5 VDC | 4 A |
| Output Current at 24 VDC | 2 A |
| Maximum Inrush Current | 25 A at 132 V AC |
| Mounting | DIN rail or panel |
| Weight | 1.38 lb (0.62 kg) |
| Estimated Shipping Dimensions | 15.5 x 13 x 8.5 cm |
| UPC | 612598276882 |
| GTIN | 10612598276889 |
Input Power and DC Output
The 1769-PA4 accepts AC input power and supplies DC power to supported CompactLogix system components. Its rated output currents differ by voltage rail: 4 A at 5 VDC and 2 A at 24 VDC. When planning a system, verify that the combined module load remains within the power supply’s applicable output ratings.
The specified power consumption varies with the input condition. The maximum inrush current of 25 A at 132 V AC is relevant when assessing power-up current and upstream protective device selection.
Mounting and Installation
The module supports both DIN rail and panel mounting. Before installation, verify the required mounting arrangement, AC input configuration, and power requirements against the equipment documentation. Also confirm that the connected system load falls within the power supply’s rated capacity.
Frequently Asked Questions
Q: What is the output current capacity of the 1769-PA4?
A: The specified current capacity is 4 A at 5 VDC and 2 A at 24 VDC. Check the power requirements of the connected components before selecting the supply for a system configuration.
Q: Does the 1769-PA4 support different AC input voltages?
A: Yes. The supplied specifications list nominal input options of 120 V AC and 220 V AC, with selectable input ranges of 85-265 V AC or 170-265 V AC. Verify the applicable configuration and input wiring requirements before energizing the module.
Q: Can the 1769-PA4 be mounted on a DIN rail?
A: Yes. The supplied specifications identify both DIN rail and panel mounting as supported options.
